Product Description:

The MSK061C-0300-NN-S1-UP0-NNNN synchronous servomotor is produced by Bosch Rexroth Indramat within the MSK IndraDyn S Synchronous Motors series. In automated production lines, the unit operates as the drive element that precisely positions tooling, conveyor sections, or robotic joints according to command values generated by a controller. By translating regulated current from the servo drive into rotational motion, it helps maintain repeatable cycle times and accurate path tracking in demanding industrial environments. With compact frame dimensions, it integrates easily into multi-axis gantries and transfer systems.

Its mechanical frame is identified as Motor Size 061, and the active stack uses Motor Length C, giving the rotor and stator a torque profile suitable for mid-range load points. Electrical characteristics follow Winding Code 0300, allowing the paired drive to apply the correct voltage and current envelopes without overstressing the coils. Heat produced during duty cycles is removed solely through natural convection, eliminating the need for external blowers or liquid circuits and simplifying cabinet layout. For feedback termination, the housing carries a rotatable 240° connector, so the encoder cable can be oriented to align with space constraints while maintaining strain relief.

Position feedback is supplied by an optical single-turn encoder that communicates via Hiperface, enabling the controller to read absolute rotor position immediately after power-up. Internal signal processing divides each mechanical revolution into 128 signal periods, providing sufficient resolution for smooth velocity loops and tight position settling. Mechanical power is transmitted through a shaft with keyway, a form that fits standard couplings and pulleys without additional machining. The motor is delivered without a holding brake, which reduces mass and moment of inertia for faster acceleration in horizontal axes where static load retention is unnecessary.
