MSK Series Synchronous Motors manufactured by Indramat, Bosch, Rexroth. This Motor features a Winding Code of 300 along with a Cooling Mode of Natural Convection.

MSK061C-0300-NN-M1-UG0-NNNN

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
MSK Series Synchronous Motors manufactured by Indramat, Bosch, Rexroth. This Motor features a Winding Code of 300 along with a Cooling Mode of Natural Convection.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a MSK061C-0300-NN-M1-UG0-NNNN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Bosch Rexroth is a global solution to industrial and motion needs among their diverse clients. With high end and state of art facilities, as well as skilled and experienced personnel, customers can rest assured that reliability and safety will be uppermost. In performance, Bosch Rexroth’s products are ultra-efficient, versatile, extreme and configurable. You can find servo drives, Brushless AC servos, drive controllers, electric controllers, synchronous motors, asynchronous motors, mains filters, and spindle drive motors, just to name a few.

Bosch Rexroth’s MSK061C-0300-NN-M1-UG0-NNNN motor has two available cooling modes, either natural or surface. In natural, the overtemperature is either 60K or 100K. In surface cooling, the overtemperature is 60K/100K.

At 100K overtemperature, the continuous current at standstill is estimated to be 4.8 amps while the continuous torque at standstill is 9.0 Nm. When at 60K overtemperature, the continuous torque at standstill stands at 8.0 Nm and the continuous current is estimated to be 4.3 amps. In surface cooling, at standstill, the continuous torque is 12 Nm and the continuous current is 6.5 amps. The maximum current in both cooling methods is 19.4 amps and the peak torque is 32 Nm.

With a temperature of 200C, the voltage constant is 125.7 V/1000min-1, its winding resistance stands at 4.5 Ohms, and the torque constant is estimated to be 2.04 Nm/A. The capacity discharge of the component is 2.4 nH, while the winding inductivity is 21.4 mH. It has 4 pairs of poles.

The rotor moment of inertia of the MSK061C-0300-NN-M1-UG0-NNNN is 0.00075 kgxm2 and the thermal time constant stands at 18 minutes. The maximum speed stands at 4200min-1 and the sound pressure level 75 dB[A]. The MSK061C-0300-NN-M1-UG0-NNNN motor weighs 8.3kg and the ambient temperature of the unit is 00C to 400C.

  • MSK 061C-0300-NN-M1-UG0-NNNN
  • MSK-061C-0300-NN-M1-UG0-NNNN
  • MSK061C 0300 NN M1 UG0 NNNN
  • MSK061C-0300-NN-M1-UG0
  • MSK061C0300NNM1UG0NNNN
  • MSK06IC-0300-NN-MI-UG0-NNNN
  • MSKO61C-0300-NN-M1-UG0-NNNN
  • MSKO61C-O3OO-NN-M1-UGO-NNNN

MSK061C-0300-NN-M1-UG0-NNNN Technical Specifications

Cooling Mode
Product MSK
Other Design None
Size 061
Length C
Winding 0300
Cooling Mode Natural Convection
Encoder Optical encoder, multiturn-absolute Hiperface, with 128 increments
Electrical Connection Plug, rotatable 240 degrees
Shaft Plain shaft with shaft sealing ring (standard)
Holding Brake Without holding brake
