The Bosch Rexroth Indramat MSK061C-0200-NN-M3-UP0-NNNN is a synchronous servomotor in the MSK IndraDyn S Synchronous Motors series. It features natural convection cooling, a shaft with keyway, and a rotatable encoder connector with Hiperface interface. This standard design motor has protection rating IP65 and operates in ambient temperatures from 0 to 40°C.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK061C-0200-NN-M3-UP0-NNNN is a synchronous servo motor produced by Bosch Rexroth Indramat and included in the MSK IndraDyn S Synchronous Motors series. The unit functions as a rotary actuator in automated machinery that requires closed-loop torque and position control. In these systems, the motor receives vector-controlled current from a drive, converts it into rotational motion, and transmits that motion through its keyed shaft to conveyors, indexing tables, or pick-and-place axes. That operating mode supports accurate positioning, repeatable acceleration, and stable speed control in demanding machine cycles.
The housing achieves IP65 protection, so dust and water jets do not reach the stator windings during washdown or cutting-fluid exposure. Heat is removed by natural convection, eliminating the need for external blowers and simplifying machine layouts. All materials and insulation conform to class 155, allowing continuous operation within ambient limits of 0 to 40 °C. Mechanical power is transmitted through a shaft with a keyway, which lets couplings lock the rotor to driven components and helps prevent slippage under cyclic torque. For feedback, the motor uses a single-cable Hiperface interface that combines encoder power and bidirectional position data in one connection. Natural cooling also keeps the motor suitable for installations where extra fan hardware would add space or wiring complexity.
The sensing unit uses a capacitive design with 16 signal periods per mechanical revolution. Because it is a multi-turn absolute device, it also records up to 4096 shaft rotations, so the axis can retain position information after power loss. Its connector can be rotated through 240° to ease cable routing in tight panels, and winding designation 0200 identifies the electrical characteristics expected by the matching drive. The standard design, motor size 061, and length C keep the motor compact for modular axes. The unit is supplied without a holding brake, which reduces rotating mass and supports high-speed duty cycles.
Frequently Asked Questions about MSK061C-0200-NN-M3-UP0-NNNN:
Q: What type of encoder interface does the MSK061C-0200-NN-M3-UP0-NNNN motor have?
A: The MSK061C-0200-NN-M3-UP0-NNNN utilizes Hiperface interface for its encoder signals.
Q: What type of shaft does the MSK061C-0200-NN-M3-UP0-NNNN provide?
A: This motor is equipped with a shaft featuring a keyway.
Q: How is the MSK061C-0200-NN-M3-UP0-NNNN cooled?
A: The cooling method for this servomotor is natural convection.
Q: Does the MSK061C-0200-NN-M3-UP0-NNNN servomotor have a holding brake?
A: This model does not include a holding brake.
Q: What is the allowable operating temperature range for the MSK061C-0200-NN-M3-UP0-NNNN?
A: The ambient operating temperature range for this motor is 0 to 40°C.
