Product Description:

The MSK060C-0600-NN-S3-UP0-NNNN is a synchronous servomotor manufactured by Bosch Rexroth Indramat within the MSK IndraDyn S Synchronous Motors series. It converts drive current into controlled rotary motion for positioning tables, pick-and-place arms, and other automated axes used in industrial production cells. When paired with a compatible drive controller, it supports closed-loop speed and position regulation so repeated moves remain accurate during changing load conditions.

This model is cooled by natural convection, so the housing surface alone transfers heat to the surrounding air, eliminating the need for forced airflow or liquid circuits. The feedback plug is a rotatable 240° connector, allowing the cable exit to be aligned with cabinet layouts without stressing the harness. Position data are exchanged through the Hiperface serial interface, which carries both incremental and absolute information over two signal pairs. Inside the encoder, a capacitive measuring head tracks rotor position, and this non-contact method tolerates vibration and dust better than optical disks. Resolution is set at 16 signal periods per mechanical revolution, giving the drive fine interpolation capability for smooth velocity control. The encoder delivers single-turn position data, and the motor is supplied without a holding brake, so mechanical lockdown must be provided externally if power-off holding torque is required.

The aluminum housing seals to IP65, blocking dust ingress and low-pressure water jets, making the unit suitable for washdown machine zones. Continuous operation is permitted from 0–40°C, and derating is required outside this ambient window to avoid thermal overload. Stator windings carry insulation rated at class 155, permitting internal temperatures up to 155 °C before material aging accelerates. Mechanical power is transmitted through a shaft with keyway, ensuring positive torque coupling to pulleys or gear sets while simplifying alignment during assembly. The C-length frame, 060 stator diameter, and 0600 winding code set the electromagnetic package and resistance values expected by IndraDrive amplifiers.
