Product Description:

The MSK060C-0600-NN-S3-UG1-NNNN is an IndraDyn S synchronous servo motor manufactured by Bosch Rexroth Indramat for the MSK IndraDyn S Synchronous Motors series. This motor provides closed-loop rotary actuation in CNC stations, assembly gantries, and printing machinery where exact speed and position control are required. It is suited to applications that need fast response, repeatable motion, and direct integration with a matching servo drive. Its frame size 060 and length code C balance continuous torque output with a compact footprint for multi-axis layouts.

Thermal management relies on natural convection, so airflow around the housing dissipates losses without fans or liquid circuits. The feedback assembly uses a rotatable connector that indexes through 240°, which helps route cables when space around the motor is limited. Inside the sensor recess, a Hiperface digital interface connects the drive to the encoder, and the system provides 16 signal periods per mechanical revolution before interpolation in the drive. The sensing principle is capacitive rather than optical, which improves tolerance to dust and oil films while preserving stable signal transmission under vibration.

The mechanical end of the motor carries a plain shaft for backlash-free clamping, while the feedback side hosts a single-turn position sensor that reports one revolution before the count resets. An electrically released brake provides 10 Nm of static torque to hold the axis when power is removed, which is useful when the load must remain in place. Environmental sealing reaches IP65, blocking dust ingress and water jets so the unit can be mounted outside the cabinet in suitable machine areas. Continuous operation is permitted from 0 to 40 °C, and class 155 insulation allows winding temperatures up to 155 °C. With its standard winding code 0600 and standard design attributes, the motor integrates directly with IndraDrive controllers that support the MSK family.
