Product Description:

The MSK060C-0600-NN-S3-BP0-NNNN is a synchronous servomotor manufactured by Bosch Rexroth Indramat within the MSK IndraDyn S Synchronous Motors series. This motor provides closed-loop torque and velocity control for automated tooling, packaging equipment, and material-handling axes, allowing the drive system to position loads accurately during repeated motion cycles. As part of an IndraDrive system, it serves as the rotary actuator while the associated drive electronics regulate current and process encoder feedback. This arrangement supports responsive motion control in applications that require repeatable acceleration, deceleration, and steady-state speed regulation.

Heat is dissipated solely by natural convection, so the housing must be installed where ambient air can circulate freely around the motor surface. Feedback signals are transmitted over a Hiperface interface that carries both incremental and absolute data to the connected drive. Internally, position is derived from 16 signal periods per mechanical revolution generated by a capacitive scanning element. Because the encoder is single-turn, the controller receives the absolute shaft angle within one revolution and must track additional turns externally when multi-turn position information is needed. The motor housing is rated IP65, which protects against dust ingress and low-pressure water jets, and the power connector is mounted on the B-side for straightforward cable routing in many machine layouts.

Operation is permitted at ambient temperatures from 0 to 40 °C, which suits common cabinet-adjacent and open-machine installations. A shaft with keyway provides positive torque transmission to pulleys, couplings, or other driven elements that need secure mechanical engagement. The thermal insulation system is class 155, supporting continuous motor operation at winding temperatures appropriate for that insulation class. The C-length version of the 060 frame, combined with winding code 0600, gives a balance of torque output and rotor inertia for dynamic axis control. Because the motor does not include a holding brake, vertical or suspended loads need an external retention method when power is removed.
