Product Description:

The MSK060C-0600-NN-S1-UG1-NNNN is a permanent-magnet AC servomotor produced by Bosch Rexroth Indramat for the MSK IndraDyn S Synchronous Motors series. Classified as an IndraDyn S synchronous servomotor, it converts drive-controller current into precisely regulated torque and speed for tightly synchronized positioning in pick-and-place gantries, carton formers, and other automated stations. Its permanent-magnet design supports responsive acceleration and stable servo control when load conditions change during repeated motion cycles.

This model follows the standard design, and its frame size is 060 with a motor length code of C; together they indicate the stator diameter and active stack length used for mounting and continuous-duty behavior. Winding code 0600 matches the motor’s electrical characteristics to compatible MSK power modules for proper current loading. Heat is removed by natural convection, so the housing fins must remain in unobstructed ambient airflow during operation. The shaft is a plain shaft, which allows direct coupling through friction-fit hubs or clamp sleeves without keys or splines and helps keep runout low.

An electrically actuated holding mechanism is integrated. The electrically-released holding brake secures the rotor when power is removed and delivers 10 Nm of static torque for vertical axes or other applications that require holding force at standstill. Feedback signals pass through a rotatable 240° encoder connector, so cable outlets can be aligned to cabinet entry points, while the data channel uses the Hiperface interface to convey position and electronic nameplate data over two differential pairs. Inside the feedback head, an optical disk with 128 signal periods and a single-turn code wheel generates accurate commutation angles and supports repeatable startup behavior.
