The Bosch Rexroth Indramat MSK060C-0600-NN-S1-UG0-NSNN is part of the MSK IndraDyn S Synchronous Motors series and features natural convection cooling and an IP65 protection rating. It has a plain shaft, a motor size of 060, and operates within an ambient temperature range of 0 to 40°C. The servomotor uses a singleturn optical encoder with Hiperface interface and a resolution of 128 signal periods.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK060C-0600-NN-S1-UG0-NSNN is an IndraDyn S synchronous servomotor produced by Bosch Rexroth Indramat and assigned to the MSK IndraDyn S Synchronous Motors series. It is intended for closed-loop motion axes where precise torque and velocity control are required in automated machinery and material-handling cells. The motor is offered in a standard configuration that also meets explosion-protection requirements. This allows the same motor type to be used in ordinary production areas as well as in hazardous locations where that protection is required.
Ingress resistance is rated at IP65, so the housing resists dust and water jets during washdown or cutting operations. Heat is removed solely by natural convection, eliminating the need for forced-air or liquid cooling hardware. Position feedback is supplied through a Hiperface optical encoder that delivers 128 signal periods per revolution, allowing accurate commutation and stable servo control. The drive end uses a plain shaft to couple with backlash-free clamping hubs or shrink discs. Because the motor is delivered without a holding brake, vertical axes require mechanical locking or drive-produced torque when power is removed.
The feedback connection uses a rotatable 240° connector, which helps with cable routing in tight cabinets or crowded machine layouts. Continuous operation is specified for a 0–40 °C ambient range, matching typical industrial operating conditions. Thermal endurance is supported by a class 155 insulation system that allows winding temperatures up to 155 °C. The motor uses a C-length stator in frame size 060 with winding code 0600, matching the electrical characteristics expected by compatible IndraDrive inverters. Its single-turn encoder architecture supports position feedback within one mechanical revolution without adding unnecessary complexity to the feedback system.
Frequently Asked Questions about MSK060C-0600-NN-S1-UG0-NSNN:
Q: What cooling method is used in the MSK060C-0600-NN-S1-UG0-NSNN motor?
A: The MSK060C-0600-NN-S1-UG0-NSNN motor is cooled by natural convection and does not require external cooling components.
Q: What is the protection rating of the MSK060C-0600-NN-S1-UG0-NSNN?
A: This model features an IP65 protection rating, providing solid protection against dust and water jets.
Q: What type of encoder is equipped on the MSK060C-0600-NN-S1-UG0-NSNN motor?
A: The MSK060C-0600-NN-S1-UG0-NSNN uses an optical singleturn encoder with Hiperface interface and 128 signal periods.
Q: What shaft type does the MSK060C-0600-NN-S1-UG0-NSNN motor use?
A: The shaft on this model is a plain shaft, suitable for applications where no keyway is required.
Q: Does the MSK060C-0600-NN-S1-UG0-NSNN come with a holding brake?
A: This motor is manufactured without a holding brake included.
