Product Description:

The MSK060C-0600-NN-M1-UP1-NNNN is an AC servomotor manufactured by Bosch Rexroth Indramat for the MSK IndraDyn S Synchronous Motors series. As a drive component, it delivers precisely regulated torque and speed, letting controllers execute coordinated motion in packaging lines, pick-and-place gantries, and handling robots. The model integrates an encoder, a keyed output shaft, and an electrically released holding brake so it can maintain position when power is removed and still return accurate feedback to the drive.

This motor is cooled by natural convection, meaning enclosure fins dissipate heat without fans or liquid circuits, so installation must allow free air circulation to keep winding temperatures within limits. Position data are transmitted through Hiperface, which combines incremental and absolute signals on one pair of conductors to simplify cabling. Inside the encoder, the scale produces 128 signal periods per revolution, and the scanning head uses an optical method to achieve fine angular resolution. Because the encoder is of the multi-turn absolute type, axis position is retained over 4096 mechanical turns without batteries, eliminating homing after shutdowns. An electrically released brake supplies 10 Nm of holding torque, securing vertical or loaded axes during emergency stops.

The mechanical interface is a shaft with a keyway, allowing direct coupling to pulleys or gearboxes while preventing slip under peak torque. A rotatable 240° feedback connector helps route cables in tight cabinets, and the housing uses the standard design used across the series. The motor has frame size 060 and length C, providing a balanced inertia-to-torque ratio for mid-range servo drives. The stator uses winding code 0600, which corresponds to a resistance and inductance set used by the drive parameter database.
