Product Description:

The Bosch Rexroth Indramat MSK060C-0300-NN-S3-UG0-NNNN belongs to the MSK IndraDyn S Synchronous Motors series and functions as a compact servomotor for precision positioning in automated transfer lines, packaging machinery, and robotics. When connected to an IndraDrive controller, it converts regulated stator current into controlled mechanical rotation while its integrated encoder returns absolute rotor angle for closed-loop control. This arrangement supports accurate motion on axes that require repeatable starts, stops, and directional changes within a compact installation space.

The frame is cooled by natural convection, so waste heat moves through the housing without auxiliary fans. A sealing system rated IP65 prevents dust ingress and low-pressure water spray, permitting installation adjacent to wash-down zones. Continuous duty is approved at ambient temperatures of 0–40 °C, maintaining insulation margins without external climate control. The feedback cable exits through a rotatable connector with 240° of adjustment, enabling strain-relieved routing regardless of machine orientation, and the communication layer is Hiperface, allowing position and parameter data to be transmitted to the drive. Inside the encoder, a capacitive sensing element resists magnetic interference, so signal quality remains stable when high switching currents are present. Stator conductors follow winding code 0300, and the 060 frame in the C length package balances torque density with envelope size for tight mounting spaces.

Fine positioning stems from an output of 16 signal periods per mechanical revolution, and because the measuring system is single-turn the absolute angle is maintained through one full turn, simplifying power-up routines. A cylindrical plain shaft transmits torque directly to couplings or gearheads without keyways that can introduce backlash. Thermal endurance reaches class 155, so the windings withstand elevated temperatures during transient overloads commanded by the drive. The unit is supplied without a holding brake, so stationary load retention must come from servo torque or an external locking device.
