Product Description:

The MSK060C-0300-NN-S2-UG0-RNNN is a synchronous servomotor manufactured by Bosch Rexroth Indramat and listed in the MSK IndraDyn S Synchronous Motors series. Within an automation cell, the motor connects to Rexroth power and control electronics to deliver closed-loop torque, velocity, and position regulation. It is deployed on pick-and-place modules, rotary actuators, and small gantries where consistent dynamic response and a compact envelope are critical.

Heat removal is handled by natural convection, eliminating external blowers and reducing maintenance points. The stator and rotor are machined for increased concentricity, a feature that minimizes runout and keeps the air gap uniform during high-speed cycles. A rotatable 240° feedback connector lets builders orient the cable exit without twisting harnesses. Position data travel over EnDat2.1, and the measuring system generates 2048 signal periods per revolution through an optical scanning process, giving fine angular resolution suitable for tight servo loops. Frame metrics include motor length C and size 060, which provide moderate continuous torque while retaining a narrow body profile. Because the unit is supplied without a holding brake, stopping torque must be provided by the drive or an external clamp.

The encoder is a single-turn device, so it supplies an absolute value within one mechanical turn and relies on the controller for multi-turn tracking. Winding code 0300 identifies the coil pitch and impedance, aligning the motor with standard MSK current ratings for medium-duty work. A plain shaft interface supports clamp or collet couplings without keyway stress concentrations, which simplifies alignment on precision gearheads. The motor is well suited for indexing tables, labeling heads, and light press axes that need accurate motion in a compact housing.
