MSK060C-0300-NN-M3-UG1-NNNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911339614
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
5 Minutes
38 Seconds
The Bosch Rexroth Indramat MSK060C-0300-NN-M3-UG1-NNNN is part of the MSK IndraDyn S Synchronous Motors series and has a standard design with a plain shaft. This servomotor features a multiturn absolute encoder with Hiperface interface and a rotatable connector, along with an electrically-released holding brake providing 10 Nm of torque. It uses natural convection for cooling and provides IP65 protection.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK060C-0300-NN-M3-UG1-NNNN servomotor belongs to the MSK IndraDyn S Synchronous Motors series and is built by Bosch Rexroth Indramat. As an IndraDyn S synchronous servomotor, it converts drive current into controlled rotary motion for indexing tables, packaging actuators, and pick-and-place axes in automated production cells. This motor type is intended for precise speed and position control when paired with a compatible drive controller. The 060 frame with C length provides the housing size used for this motor variant.
Heat is dissipated through natural convection, so no auxiliary cooling equipment is required. The motor uses a single-cable feedback assembly built around a Hiperface interface, and this serial link carries position data from a capacitive sensing element with 16 signal periods per mechanical revolution. Because the scan head is resistant to magnetic fields, feedback accuracy is maintained near high-current busbars and other powered conductors. The feedback system is multi-turn absolute, so position can be recovered after power loss without external batteries. A rotatable 240° connector simplifies cable routing inside tight enclosures, and this arrangement helps reduce cable movement around adjacent machine components. Winding code 0300 provides the electrical values expected by the matching drive controller.
The electrically released holding brake supplies 10 Nm of static torque, helping keep the smooth shaft stationary when supply power is removed on vertical axes. The housing is sealed to IP65, and continuous service is permitted at ambient temperatures from 0 to 40 °C. Insulation class 155 allows winding temperatures up to 155 °C, providing thermal capacity for short duty-cycle overloads. The plain shaft interface supports direct coupling to precision gearheads and similar transmission components. The brake connector can be rotated to match the encoder connector orientation, which helps keep cable routing orderly without twisting the harness.
Frequently Asked Questions about MSK060C-0300-NN-M3-UG1-NNNN:
Q: What type of encoder is used in the MSK060C-0300-NN-M3-UG1-NNNN motor?
A: The MSK060C-0300-NN-M3-UG1-NNNN is equipped with a multiturn absolute encoder using capacitive Hiperface technology for precise position feedback.
Q: How is the MSK060C-0300-NN-M3-UG1-NNNN motor cooled?
A: This motor is cooled through natural convection, meaning it does not require external fans or cooling devices.
Q: What is the holding brake torque and release method on the MSK060C-0300-NN-M3-UG1-NNNN?
A: The holding brake on this model provides 10 Nm of torque and is electrically released.
Q: What type of shaft does the MSK060C-0300-NN-M3-UG1-NNNN motor have?
A: The MSK060C-0300-NN-M3-UG1-NNNN features a plain shaft for direct coupling to mechanical components.
Q: What level of protection does the MSK060C-0300-NN-M3-UG1-NNNN motor have?
A: This servo motor is rated IP65, offering complete protection against dust and low-pressure water jets.
