The Bosch Rexroth Indramat MSK060C-0300-NN-M1-UG1-NSNN is part of the MSK IndraDyn S Synchronous Motors series and features natural convection cooling and an IP65 protection rating. This synchronous servomotor has a plain shaft, motor size 060 and length C, and operates in ambient temperatures from 0 to 40°C. It uses an optical multiturn absolute encoder with Hiperface interface and 128 signal periods, and includes an electrically released holding brake with a torque of 10 Nm.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK060C-0300-NN-M1-UG1-NSNN is a servo motor built by Bosch Rexroth Indramat for the MSK IndraDyn S Synchronous Motors series. Within automated packaging, handling, and metal-cutting stations, the unit converts drive controller current into precise rotor motion so that axes follow commanded positions and speeds. The model carries the 060 frame code and C length designation, pairing moderate inertia with installation flexibility in multi-axis assemblies.
Thermal management relies on natural convection, so no forced-air or liquid circuits are required. This cooling method simplifies installation and supports the motor's continuous duty profile. The stator winding follows code 0300 for voltage and current pairing with compatible Rexroth drives. Feedback is delivered through a rotatable 240° connector that connects to drives through the Hiperface digital interface. Inside the encoder housing, an optical sensor tracks 128 signal periods per revolution and stores position with multiturn absolute capability, eliminating homing moves after power loss. For static holding or emergency stops, an electrically released brake supplies 10 Nm of torque to lock the shaft without external actuators. The design variant can also be ordered for explosion-protected zones, extending use into volatile process areas.
The housing carries an IP65 rating, sealing the stator and encoder against dust ingress and low-pressure water jets so the motor can mount directly on machines without an additional enclosure. Safe operation is specified within an ambient range of 0 to 40 °C, which aligns with most control cabinets that use passive ventilation. A plain shaft simplifies coupling to gearboxes or belt pulleys because there are no keyways or serrations to machine. The insulation system uses class 155, allowing winding temperatures well above the surrounding air without loss of dielectric strength.
Frequently Asked Questions about MSK060C-0300-NN-M1-UG1-NSNN:
Q: What cooling method does the MSK060C-0300-NN-M1-UG1-NSNN motor use?
A: This motor is cooled by natural convection, allowing it to operate without external fans or forced cooling.
Q: What type of encoder interface and feedback does the MSK060C-0300-NN-M1-UG1-NSNN motor use?
A: The encoder interface on this model is Hiperface and provides multiturn absolute feedback using optical technology.
Q: Is the MSK060C-0300-NN-M1-UG1-NSNN equipped with a holding brake and what is its torque?
A: A holding brake with 10 Nm torque that is electrically released is integrated into this motor.
Q: What is the adjustability of the encoder connector on the MSK060C-0300-NN-M1-UG1-NSNN?
A: The encoder connector on this motor is rotatable up to 240°, offering flexible installation options.
Q: What level of environmental protection does the MSK060C-0300-NN-M1-UG1-NSNN motor provide?
A: This model has an IP65 protection rating, meaning it is dust tight and protected against water jets.
