Product Description:

The MSK060B-0600-NN-S3-UP0-NNNN is a synchronous servo motor manufactured by Bosch Rexroth Indramat and assigned to the MSK IndraDyn S Synchronous Motors series. Its 060 frame size and B-length housing place it in the lower-torque range of the platform, making it suitable for positioning tables, pick-and-place gantries, and other medium-inertia axes in industrial automation. It converts drive current from an IndraDrive controller into precise shaft motion and encoder feedback for closed-loop speed and position control on assembly or packaging machines. That makes it a practical choice for repeatable indexing and transfer tasks that depend on accurate starts, stops, and speed changes. The compact mechanical envelope also helps the motor fit installations where responsive motion is needed without moving to a larger frame.

Thermal management relies on natural convection, so the housing dissipates heat without external fans and keeps the installation simple. The stator uses winding code 0600, which corresponds to the electrical characteristics available for this motor size. Position data are exchanged through a Hiperface interface, and the encoder uses a capacitive measuring principle with 16 signal periods to provide feedback suited to mid-range accuracy requirements. This arrangement gives the drive steady position information for normal servo regulation without requiring a separate external feedback device. Natural cooling also removes the need for auxiliary airflow hardware around the motor.

The feedback connector is rotatable through 240°, allowing the cable outlet to be adjusted for tight machine layouts or restricted bend space. Because the encoder is a single-turn type, it reports absolute position within one revolution and the drive handles multi-turn tracking separately. Mechanical power is transmitted through a shaft with a keyway, which provides a secure connection to pulleys, couplings, or gear inputs. The motor is supplied without a holding brake, so any load that must remain fixed at standstill needs holding torque from the drive or an external mechanical device. The absence of a brake keeps the package simpler where static load holding is not required.
