Product Description:

The MSK060B-0600-NN-S1-UG1-NNNN is an IndraDyn S synchronous servomotor produced by Bosch Rexroth Indramat for applications that demand precise speed and position control. Operating in the MSK IndraDyn S Synchronous Motors series, the unit supplies rotary motion to feed axes, pick-and-place heads, and ancillary tooling within automated lines. Its standard mechanical design lets it fit into machine frames without custom adapters, and compatibility with single-cable feedback architectures streamlines installation.

Thermal management relies on natural convection, eliminating the need for fans or liquid circuits and allowing vertically mounted units to dissipate heat through the housing ribs. The electromagnetic section follows winding code 0600, a designation that matches the drive to specific voltage and current ratings used in 400 V DC-link inverters. Position feedback resolution reaches 128 signal periods per mechanical revolution, and when interpolated by the drive this provides very fine positioning. Communication travels over the Hiperface interface, enabling digital feedback data transmission through the hybrid cable. An electrically released holding brake supplies 10 Nm of torque so the shaft can be locked during power loss or safety stops without drawing current.

The output end is a plain shaft, simplifying coupler selection for gearboxes or pulley drives while eliminating keyway stresses. Feedback wiring exits through a rotatable 240° encoder connector, so the plug can be oriented away from obstacles while maintaining minimum bend radii. Classified as motor size 060, the housing diameter and flange pattern align with other 60 mm frame components in the IndraDyn platform, which helps maintain consistent mounting dimensions. Inside the encoder, an optical scanning system works in single-turn mode, generating absolute position data for each revolution without relying on batteries or multi-turn gears.
