Product Description:

The MSK060B-0300-NN-S1-UP0-NSNN servo motor is produced by Bosch Rexroth Indramat as part of the MSK IndraDyn S Synchronous Motors series. It is intended for closed-loop motion axes in packaging machines, handling systems, and general automation lines where precise position control and repeatable speed regulation are required. The motor converts electrical energy from a compatible drive into controlled rotary torque, which helps synchronize conveyors, tooling, and other moving elements with accurate response during changing load conditions.

It achieves heat dissipation through natural convection, eliminating the need for external blowers while keeping the stator within safe limits under continuous duty. The housing carries an IP65 rating that helps keep dust and low-pressure water jets away from internal components. Position feedback is provided by an optical encoder with 128 signal periods per revolution that communicates through Hiperface, giving the drive a digital feedback channel for position and speed control. The feedback plug can rotate through 240°, which makes cable routing easier in confined spaces, and winding code 0300 sets the electrical values expected by the matching drive. This design variant is suitable for standard installations and applications that require explosion protection.

The feedback system is a single-turn type, so the drive can reference absolute position within one mechanical revolution. The motor is intended for ambient temperatures from 0–40 °C, and its insulation system is rated at 155 to limit thermal aging during repeated duty cycles. It does not include a holding brake, so static loads must be secured by drive torque or an external device. A shaft with keyway supports positive torque transmission to pulleys or couplings, and the size 060 frame with length code B helps keep inertia low for rapid start-stop motion.
