MSK050C-0600-NN-M1-UP0-NNNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911299914
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat MSK050C-0600-NN-M1-UP0-NNNN is part of the MSK IndraDyn S Synchronous Motors series. This standard design servomotor features natural convection cooling and a shaft with keyway. It uses a multiturn absolute optical encoder with a resolution of 128 signal periods and a Hiperface interface, and does not include a holding brake.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSK050C-0600-NN-M1-UP0-NNNN is an IndraDyn S synchronous servomotor manufactured by Bosch Rexroth Indramat for the MSK IndraDyn S Synchronous Motors series. The unit converts three-phase drive current into precisely regulated rotary motion, allowing CNC tables, pick-and-place arms, and conveyor sections to reach commanded positions repeatedly. It is intended for servo axes that require accurate speed and position control during frequent start-stop cycles. Its 050 frame diameter and C length provide high torque density in a compact housing, which helps the motor fit installations where space is limited. Its synchronous design also supports responsive acceleration and repeatable positioning in automated production cells.
Thermal management relies on natural convection, so the housing fins dissipate heat without external fans or liquid circuits. The encoder plug is rotatable through 240°, which simplifies cable routing where clearance is limited. Position feedback is transmitted over the Hiperface serial interface, and the optical scanning system provides 128 signal periods per mechanical revolution for interpolation by the drive. Because the sensor is optical, electrical noise from nearby switching devices does not affect the position data. This feedback arrangement supports stable commutation and smooth motion at low and changing speeds, and the cooling method avoids added airflow hardware around the motor body.
The encoder is a multiturn absolute unit, so the controller retains a unique position reference across 4,096 shaft revolutions without battery-backed homing. The motor is supplied without a holding brake, so load holding during power-off conditions must be provided externally when the application requires it. Mechanical power is transmitted through a shaft with keyway, allowing the use of conventional keyed couplings and pulleys. Electrical behavior is matched to IndraDrive power stages by winding code 0600, which indicates the motor's resistance and inductance values for stable current control. This combination suits compact servo applications that need accurate feedback and direct mechanical coupling.
Frequently Asked Questions about MSK050C-0600-NN-M1-UP0-NNNN:
Q: What type of cooling method is used in the MSK050C-0600-NN-M1-UP0-NNNN motor?
A: This model uses a natural convection cooling system and operates without forced air or liquid cooling.
Q: What type of encoder does the MSK050C-0600-NN-M1-UP0-NNNN use?
A: The MSK050C-0600-NN-M1-UP0-NNNN is equipped with a multiturn absolute optical encoder using Hiperface interface.
Q: Does the MSK050C-0600-NN-M1-UP0-NNNN motor come with a holding brake?
A: This motor does not include a holding brake.
Q: What kind of shaft design is provided on the MSK050C-0600-NN-M1-UP0-NNNN?
A: The shaft features a keyway for secure coupling of mechanical components.
Q: How is the encoder connector configured on the MSK050C-0600-NN-M1-UP0-NNNN?
A: The encoder connector on this model is rotatable up to 240° for flexible installation.
