Product Description:

The MSK050C-0600-NN-M1-UG1-NNNN is an IndraDyn S synchronous servomotor produced by Bosch Rexroth Indramat within the MSK IndraDyn S Synchronous Motors series. It converts the regulated output of an IndraDrive inverter into controlled rotary motion for tasks such as indexing tables, carton formers, and small-gantry axes in automated lines. Integrated feedback, a power-off brake, and standard mounting geometry allow the motor to fit directly into multi-axis assemblies that require repeatable positioning and compact installation space.

Heat generated by the stator windings is removed through natural convection, so the motor can be mounted in sealed cabinets without forced airflow. Position loops close over a Hiperface interface that carries both encoder data and electronic nameplate information on a single hybrid cable. The optical sensor yields 128 signal periods per revolution, giving the controller fine resolution for sub-millimeter linear travel when the motor drives a belt or ball screw. An electrically released brake supplies 6 Nm of static holding torque to secure vertical axes during power loss. A plain shaft without a keyway reduces hub misalignment and permits the use of backlash-free clamping couplings for better torsional stiffness.

The feedback device is a multi-turn absolute encoder, which retains shaft position over 4,096 turns and eliminates homing after emergency stops. Service routing is simplified by a 240° rotatable connector that lets the cable exit upward, sideways, or downward depending on panel layout. The motor keeps the standard housing outline of the series and occupies frame size 050, which helps it fit into tightly spaced machine layouts. With winding code 0600 and the intermediate length C stator stack, the torque-speed curve is suited to medium-inertia loads found on pick-and-place heads and compact conveyors.
