MSK050B-0300-NN-M1-UG1-NNNN

 Rated 4.7 with 9 reviews

Description:

MSK Series Synchronous Motors manufactured by Indramat, Bosch, Rexroth. This Motor features a Winding Code of 300 along with a Cooling Mode of Natural Convection.

Available, Call for Quote
Request a Repair
Warranty Shipping Repairs Exchange
1 Year Wake Industrial Warranty included Worldwide shipping via DHL, UPS, and Fedex Repair options are available for this unit Exchange credit for your defective unit available.

To Speak to a sales representative for pricing & lead time:

Phone

1-800-551-3082

International

919-443-0207

The MSK050B-0300-NN-M1-UG1-NNNN is a servomotor designed by IndraDyn S motors to stand out as one of the best in the industry. It boasts of a high torque density, excellent dynamics, compact construction and an extremely high degree of precision.

How does the MSK050B-0300-NN-M1-UG1-NNNN servomotor work?

You need to have full information on the rotors current position to control the speed or position of the MSK050B-0300-NN-M1-UG1-NNNN servomotor. The integrated encoder unit ensures the right signal is sent to the drive controller. The drive controller can transmit the determined position value in this way to a superordinate controller.

The encoder electronics consist of data memory for storing the motor type name, motor and control loop parameters. These data are then read out by the Rexroth drive control devices. The advantages of these include:

  • Fast and seamless startup.
  • A true partnership between the drive controller and motor without exposing the engine to the risk of damage.

The MSK050B-0300-NN-M1-UG1-NNNN continuous torque at a standstill is 3.4Nm, constant current at the stop of 1.8A and maximum torque of 9Nm. Its maximum current is rated at 7.2 A, winding inductivity 76,400 mH, and maximum speed at 4300 min-1

The MSK050B-0300-NN-M1-UG1-NNNN is designed with 4 pairs of poles and offers IP 65 degree of protection. The housing design is made of natural convection and has a possibility of fan mounting and a standard shaft sealing ring. It comprises of a holding brake with the electrical release of 6Nm and electrical connection plug which is 240 degrees rotatable.

It has an optical encoder and multiturn-absolute Hiperface with 128 increments. These encoders allow for complete indirect position recording of about 4096 mechanical rotations.

Product: MSK
Size: 050
Length: B
Winding: 0300
Cooling Mode: Natural Convection
Encoder: Optical encoder, multiturn-absolute Hiperface, with 128 increments
Electrical Connection: Plug, rotatable 240 degrees
Shaft: Plain shaft with shaft sealing ring (standard)
Holding Brake: Holding brake, electrically released, 6 Nm
Other Design: None
