Product Description:

The MSK040B-0600-NN-S1-UP0-NNNN is an IndraDyn S synchronous servomotor produced by Bosch Rexroth Indramat for the MSK IndraDyn S Synchronous Motors series. As a compact rotary drive element, the unit converts controlled electrical power from a compatible drive into precise mechanical torque and speed for positioning axes, pick-and-place gantries, and packaging machines in automated production cells. In closed-loop motion systems, it supports accurate acceleration, deceleration, and position holding during repetitive machine cycles. The motor uses frame size 040 with length code B, giving a compact footprint while providing enough active material for responsive servo performance.

Thermal management relies on natural convection, meaning heat dissipates through the aluminum housing without fans or liquid circuits. The feedback system uses a Hiperface interface with an optical sensor. The encoder provides 128 signal periods per revolution for commutation and position evaluation. Because it is single-turn, it reports absolute position within one mechanical revolution, while turn-to-turn tracking must come from the connected control system. The B-length motor body provides additional stator length for the winding and supports higher continuous output than a shorter housing in the same frame size.

Electrical installation is simplified by a rotatable 240° encoder connector, so the feedback cable can be directed to suit the available machine space. The motor is supplied without a holding brake, so any vertical or suspended load must be secured by external means when power is removed. Output torque is transmitted through a shaft with a keyway, which is suitable for pulleys, gears, and rigid hubs. The 0600 winding code identifies the electrical layout used for this motor and matches it to compatible drive stages. The housing remains compact because no active cooling hardware is required.
