Product Description:

The MSK035C-0600-NN-S1-UG0-NNNN synchronous servo motor is produced by Bosch Rexroth Indramat as part of the MSK IndraDyn S Synchronous Motors series. It is intended for use with an electronic drive controller, where it provides closed-loop rotary motion for packaging platens, pick-and-place heads, and light material-handling axes. The compact motor layout supports installations where precise positioning and repeatable speed control are required in a limited space. When matched with a suitable controller, it converts commanded electrical input into controlled shaft movement during starting, stopping, and speed changes.

Heat generated by the stator is released through natural convection, allowing continuous duty when ambient air can circulate freely around the housing. Feedback is transmitted on a bidirectional serial link that uses the Hiperface protocol, so the drive receives both position data and electronic motor information through the same interface. The integrated optical sensor produces 128 signal periods per mechanical revolution, which gives fine commutation increments for smooth motion control. Because the encoder is a single-turn device, it reports the absolute shaft angle within one revolution while the control system tracks accumulated turns separately. An enclosure rating of IP65 helps protect the motor against dust and low-pressure water jets commonly found in industrial environments.

There is no holding brake in this configuration, so power-off position retention must be provided by an external clamping device or another mechanical restraint. The encoder connector is rotatable through 240°, which helps with cable routing in tight machine frames and reduces strain caused by awkward cable entry angles. Output torque is transferred by a plain shaft, allowing direct connection to suitable backlash-free couplings. Continuous operation is permitted in ambient temperatures from 0–40 °C, and the windings use insulation class 155 to withstand normal thermal rise during operation. This combination suits light servo axes that need compact motor dimensions, reliable feedback, and simple external cooling.
