Product Description:

The MSK030C-0900-NN-S3-UP0-NNNN is an IndraDyn S synchronous servo motor in the MSK IndraDyn S Synchronous Motors series from Bosch Rexroth Indramat. It supplies closed-loop torque and position control to automated machinery and acts as a core electromechanical actuator in industrial automation lines. The motor body uses a standard geometric design that aligns with the MSK mounting pattern, which helps it fit established machine layouts. This compact construction supports use on axes where available installation space is limited but accurate motion control is still required.

Cooling is handled by natural convection, so the housing surface removes operational heat without auxiliary airflow. A rotatable, 240° encoder connector allows the plug position to be adjusted for easier cable routing. The sensing element communicates through the Hiperface serial interface, allowing power and data on one cord set. Inside the feedback module, a capacitive measuring cell tracks rotor angle and offers resistance to dust and oil. The feedback scale is divided into 16 signal periods per mechanical turn, giving the drive finely interpolated position data. The motor is supplied without a holding brake, so stationary loads must be secured by external clamping or drive torque when power is removed.

The frame size 030 gives the motor a small cross-section for tight machine envelopes. Length code C extends the active stack to increase continuous output within that footprint. Electrically, winding code 0900 sets the resistance and inductance values expected by compatible IndraDrive amplifiers. Mechanical coupling is performed through a shaft with keyway, which provides positive torque transfer without slippage. A single-turn encoder reports absolute position for one revolution, allowing immediate motion synchronization after power-up. This arrangement supports accurate axis startup and stable integration with matching drive electronics.
