Product Description:

The MSK030C-0900-NN-M3-UP1-NNNN synchronous servomotor is produced by Bosch Rexroth Indramat for the MSK IndraDyn S Synchronous Motors series. As an IndraDyn S synchronous servomotor, it converts drive-controller output into precise rotary motion for conveyor lanes, pick-and-place heads, and tool spindles. The compact 030 frame allows placement in machines with limited mounting depth. This layout makes the motor suitable for tightly packed automation equipment where accurate motion must be delivered from a small installation space.

Its standard housing uses natural convection to remove heat from the stator, eliminating external blowers and reducing the need for auxiliary cooling hardware. Frame size 030 and length code C provide a compact motor body, while winding code 0900 matches the electrical characteristics used with compatible IndraDrive amplifiers. The electrically released holding brake supplies 1 Nm of static torque to lock the axis when mains power is absent. Environmental sealing to IP65 blocks dust and low-pressure water jets, supporting direct machine mounting. Thermal endurance is provided by insulation class 155, and continuous operation is permitted at ambient temperatures of 0 to 40 °C without derating.

Position feedback is handled through a Hiperface serial channel that transfers absolute position data and electronic nameplate information to the drive. The sensing element uses capacitive scanning and delivers 16 signal periods per mechanical turn for stable commutation at low and high speeds. Stored turn counting across 4096 revolutions is available through its multiturn absolute capability, so the axis can return to operation without a homing cycle after power loss. The feedback connector can rotate 240° to suit cable routing in tight assemblies. A shaft with keyway transfers torque to couplings or gears with a secure mechanical connection.
