Product Description:

The MHP115C-024-HP0-BNNNNN is a synchronous servo motor built by Bosch Rexroth Indramat for the MHP Synchronous Motors series. It serves as the mechanical actuator in closed-loop automation, supplying precise rotational motion to production lines, pick-and-place arms, and coordinated multi-axis platforms where repeatable positioning is required. When paired with a compatible drive, it supports accurate indexing, stable speed regulation, and synchronized axis movement during repetitive machine cycles. This makes it suitable for applications that must start, stop, and reverse smoothly while maintaining consistent motion control.

Under natural cooling, the motor delivers a continuous standstill torque of 70.0 Nm, allowing high holding force without additional fans. The housing is rated IP65, so dust ingress and low-pressure water jets do not affect the internal windings. Position feedback is provided by an incremental encoder with 2048 increments, supplying fine-resolution signals for the controller’s velocity and position loops. Power reaches the load through a keyed shaft with a sealing ring, which transmits torque while helping prevent lubricant migration. Reliable operation is maintained at ambient temperatures from 0 to +40 °C, matching typical production and workshop conditions without derating.

The stator uses natural convection cooling, so heat dissipates through the ribbed frame rather than through forced airflow. For emergency or power-off situations, the unit is supplied without a holding brake, so any static load retention must be handled by the drive or by external locking devices. Class F insulation permits winding temperatures up to 155 °C, helping the motor tolerate repeated thermal cycling in normal industrial service. The electrical design uses winding code 024, which sets the phase resistance and inductance values used for drive matching. The motor has size 115 and length C, and the power connector is oriented toward side B for standard machine layouts.
