Product Description:

The MHP115B-024-HG1-AFNNNN is a synchronous servo motor produced by Bosch Rexroth Indramat for the MHP Synchronous Motors series. It is intended for closed-loop industrial automation axes where precise velocity and torque control are needed to position tooling, conveyor sections, or gantry tables under demanding duty cycles. This makes the motor suitable for applications that require stable response during frequent starts, stops, and load changes.

The motor can deliver a standstill torque of 50.0 Nm when cooled only by natural convection, allowing static loads to be held without movement while current is maintained. A housing prepared for liquid cooling increases continuous output by removing heat directly from the stator jacket. The motor is rated IP65, which helps protect internal parts from dust and water jets during operation. Rotor position data are generated by an integrated incremental encoder with 2048 increments, allowing the associated drive controller to maintain accurate speed and position regulation. The ambient temperature should remain within 0 to +40 °C to help preserve bearing lubrication and insulation life.

An integrated brake supplies 70.0 Nm of holding torque when power is removed, helping prevent axis drift on vertical or safety-related axes. The motor uses insulation class F, which permits winding temperatures up to 155 °C during short-term overload. It has a plain shaft with a sealing ring to help limit lubricant escape and reduce contaminant entry at the output interface. The motor has frame size 115 with a B length, giving it the mechanical envelope associated with this model. Winding code 024 matches the electrical characteristics expected by compatible drive inverters, and power is routed through a connector on side A for consistent cable entry.
