Product Description:

The MHP112C-024-HP3-ANNNNN is a synchronous servo motor manufactured by Bosch Rexroth Indramat for the MHP Synchronous Motors series. It interfaces with digital drive controllers to supply closed-loop speed and position control in automated machinery. Frame size 112 and length code C give a package that balances torque output with installation depth, making the unit suitable for presses, packaging stations, and material-handling axes. Its synchronous design supports repeatable acceleration and steady running in applications that cycle frequently or require accurate stopping points.

Under natural convection cooling, the motor produces a continuous stall torque of 38.0 to 43.5 Nm, providing stable drive force without external fans. During power-off events, the integrated brake applies 70.0 Nm of holding torque to secure vertical or indexing loads. Rotor position is reported by an incremental encoder with 2048 increments, enabling precise velocity regulation. Windings built to insulation class F permit winding temperatures up to 155 °C for extended duty cycles. A sealed housing rated at IP65 shields the stator and connectors from dust and low-pressure water jets, simplifying installation on open machine frames. The feedback system also helps the drive maintain stable commutation during low-speed motion and positioning tasks.

The motor is intended for ambient conditions of 0 to +40 °C, so it can be installed in standard industrial work areas without added cooling equipment. Power conductors exit through a connector on side A, which can simplify cable routing beside a gearbox or bearing block. Output torque is delivered by a keyed shaft with a sealing ring, and the seal helps limit lubricant migration while reducing the entry of dust or moisture near the shaft opening. The stator winding uses code 024, which matches the electrical characteristics expected by compatible drives.
