MHP112C-024-HG0-ANNNNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911288306
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
6 Minutes
50 Seconds
The Bosch Rexroth Indramat MHP112C-024-HG0-ANNNNN is part of the MHP Synchronous Motors series and features a plain shaft with a sealing ring. It comes with an incremental encoder offering 2048 increments for motor feedback and is rated with IP65 protection. This model delivers a continuous torque at standstill between 38.0 and 43.5 Newton-meters using natural convection cooling.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MHP112C-024-HG0-ANNNNN is a synchronous motor built by Bosch Rexroth Indramat for the MHP Synchronous Motors series. It serves as a drive element in automated machinery, delivering controlled rotary motion when paired with a compatible inverter for positioning and speed-controlled tasks. The housing uses natural convection cooling, and the motor is supplied without a holding brake, so position holding after power loss must come from drive torque or an external locking device. This arrangement suits installations where the motor can release heat through its outer surface without auxiliary cooling hardware.
During continuous operation, the motor can run in ambient conditions from 0 to +40 °C, and its standstill torque under natural convection ranges from 38.0 to 43.5 Nm. A plain shaft with a sealing ring transmits torque to the load while helping reduce lubricant escape at the bearing journal. The enclosure is rated IP65, which keeps out dust and resists water jets in typical industrial settings. The windings use insulation class F, allowing winding temperatures up to 155 °C before thermal limits are reached. For stable thermal performance, the motor should be installed with open space around the housing so air can circulate freely.
Position and speed feedback are supplied by an incremental encoder with 2048 increments per revolution, supporting fine resolution in servo control loops. Electromechanical behavior corresponds to winding code 024, which sets the resistance, inductance, and rated current used for drive matching. Power and signal leads exit toward the mounting flange because the connector is on side A. The motor uses motor size 112 with length code C, giving a mid-range rotor stack within the series. That frame and length combination suits applications that need a balance between torque density and overall motor length.
Frequently Asked Questions about MHP112C-024-HG0-ANNNNN:
Q: What is the allowed ambient temperature for the MHP112C-024-HG0-ANNNNN motor?
A: The MHP112C-024-HG0-ANNNNN operates within an ambient temperature range of 0 to +40°C.
Q: What is the continuous torque at standstill for the MHP112C-024-HG0-ANNNNN?
A: This model provides a continuous standstill torque between 38.0 and 43.5 Nm when cooled by natural convection.
Q: What type of drive shaft does the MHP112C-024-HG0-ANNNNN motor use?
A: The drive shaft features a plain shaft design with a sealing ring for reliable operation.
Q: Is a holding brake included in the MHP112C-024-HG0-ANNNNN motor?
A: The MHP112C-024-HG0-ANNNNN does not include an integrated holding brake.
Q: What type of motor feedback is provided on the MHP112C-024-HG0-ANNNNN?
A: This motor is equipped with an incremental encoder offering 2048 increments for feedback.
