Product Description:

The MHP112B-024-HP1-ANNNNN is a synchronous servo motor produced by Bosch Rexroth Indramat as part of the MHP Synchronous Motors series. This 112-frame unit converts electrical energy from a matched drive into controlled mechanical rotation. It is suitable for positioning tables, printing cylinders, and packaging axes that need consistent torque and repeatable speed. In servo applications, that combination supports smooth acceleration, stable low-speed movement, and accurate response to changing load commands.

With a continuous standstill torque of 28.0 to 31.0 Nm when cooled by natural convection, the motor can hold or slowly drive loads without external fans. Because heat is released through the housing surface instead of an auxiliary blower, the installation remains simple and avoids extra airflow hardware. A built-in holding brake supplies 22.0 Nm of static locking torque to help secure the axis when power is removed or the axis is parked. The insulation system has a class F rating, so the windings can tolerate elevated operating temperatures within the intended duty range. Operation is permitted in ambient air from 0 to +40 °C, which suits standard industrial spaces.

Closed-loop motion control is supported by an incremental encoder with 2048 increments, giving the controller fine positional granularity across each revolution. The feedback signal supports precise speed regulation and position correction by the connected controller. Winding designation 024 indicates the electrical characteristics used with matching Rexroth power modules in the appropriate voltage range. Power is supplied through a connector on side A, which keeps cabling on the drive side of the machine frame and can simplify routing in compact layouts. A keyed shaft with a sealing ring transmits torque to the driven load, and the IP65 enclosure helps protect internal components from dust and low-pressure water streams encountered in manufacturing cells.
