MHP112B-024-HG1-BNNNNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911297171
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
6 Minutes
0 Seconds
The Bosch Rexroth Indramat MHP112B-024-HG1-BNNNNN is part of the MHP Synchronous Motors series and features a plain shaft with a sealing ring and a holding brake with a torque of 22 Nm. It uses an incremental encoder with 2048 increments for motor feedback, supports natural convection cooling, and has an IP65 protection category. The motor is built to insulation class F and operates within an ambient temperature range of 0 to 40°C.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MHP112B-024-HG1-BNNNNN synchronous motor is produced by Bosch Rexroth Indramat as part of the MHP Synchronous Motors series. Designed for position and velocity control in automated machinery, it converts drive current from a compatible inverter into precise mechanical rotation on medium-to-large axes. Its synchronous design supports stable closed-loop operation, allowing the drive to maintain accurate speed and position during repeated motion cycles. This makes the motor suitable for equipment that requires consistent response during indexing, feeding, and coordinated axis movement.
Within its natural-convection housing, the motor can generate a continuous standstill torque of 28.0 to 31.0 Nm, giving machinery steady holding force without forced cooling. A built-in holding brake supplies 22.0 Nm of static torque so vertical or indexing axes remain fixed when power is removed. Rotor position is returned to the controller by an incremental encoder that produces 2048 increments per revolution, enabling fine interpolation for smooth motion. The plain output shaft is fitted with a sealing ring that helps block lubricant escape and supports the IP65 enclosure rating, which keeps dust and low-pressure water jets away from internal components. Because the housing relies on natural convection, heat is dissipated through the outer surface rather than by a fan, which reduces maintenance requirements and operating noise.
Thermally, the unit operates in ambient conditions from 0 to +40 °C, so it may be installed in standard machine environments without separate cooling hardware. Class F insulation permits winding temperatures up to 155 °C, matching the heat rise associated with winding code 024. Power cabling attaches through a connector on side B, allowing consistent panel layouts when multiple motors share the same orientation. The motor uses size 112 with a compact length B, giving a balanced ratio of inertia to torque for packaging, printing, and material-handling stations. This side-mounted connection also helps keep cable routing clear of the drive end in enclosed machine layouts.
Frequently Asked Questions about MHP112B-024-HG1-BNNNNN:
Q: What type of motor feedback does the MHP112B-024-HG1-BNNNNN motor provide?
A: The MHP112B-024-HG1-BNNNNN synchronous motor uses an incremental encoder with 2048 increments for feedback.
Q: What kind of drive shaft is included with the MHP112B-024-HG1-BNNNNN motor?
A: This model is equipped with a plain drive shaft that includes a sealing ring for enhanced protection.
Q: What is the continuous standstill torque of the MHP112B-024-HG1-BNNNNN motor?
A: The motor offers a continuous standstill torque between 28.0 to 31.0 Nm under natural convection conditions.
Q: What is the holding brake torque specification for the MHP112B-024-HG1-BNNNNN motor?
A: The holding brake provides a torque output of 22.0 Nm for secure braking operations.
Q: What is the protection rating of the MHP112B-024-HG1-BNNNNN synchronous motor?
A: This motor features an IP65 protection category, shielding it from dust and low-pressure water jets.
