MHP112B-024-HG0-ANNNNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911284275
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
6 Minutes
45 Seconds
The Bosch Rexroth Indramat MHP112B-024-HG0-ANNNNN is part of the MHP Synchronous Motors series and features a plain shaft with a sealing ring. The motor has a continuous torque at standstill of 28.0 to 31.0 Nm and uses an incremental encoder with 2048 increments for feedback. It operates within an ambient temperature range of 0 to 40°C and has IP65 protection.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MHP112B-024-HG0-ANNNNN synchronous motor is produced by Bosch Rexroth Indramat within the MHP Synchronous Motors series. This AC motor is installed in industrial automation where closed-loop drives must deliver precise speed and position control to conveyors, machining axes, or material-handling gantries. Its electromechanical design supports direct coupling to servo drives for repeatable motion sequences. Because it is a synchronous design, the drive can regulate rotor movement accurately during indexing, velocity control, and coordinated axis travel. This makes the motor suitable for equipment that depends on repeatable starts, stops, and direction changes during automated cycles.
In continuous duty, the motor delivers 28.0 to 31.0 Nm of standstill torque when cooled only by ambient airflow. Operation is permitted between 0 to +40 °C, so the enclosure must stay inside this temperature range to avoid derating. The housing has an IP65 rating, sealing the stator against dust and low-pressure water jets. Position feedback comes from an incremental encoder with 2048 increments, giving the drive precise position data. Mechanical power exits through a plain shaft with a sealing ring, which helps block lubricant migration while allowing direct coupling to gearboxes or pulleys. Heat is dissipated through the aluminum frame by natural convection, so no forced-air ducts are required. The stator windings use F-class insulation, tolerating winding temperatures up to 155 °C.
Power enters through a connector on side A, simplifying cable routing when the motor is mounted with its output shaft toward the machine centerline. The frame code 112 indicates the stator diameter and matches drive sizing tables for medium-inertia loads, while the letter B in the type code specifies the second longest housing length available for this model. Coil set 024 aligns electrical resistance and inductance with standard Indramat drives for 400 V buses. The motor has no holding brake, so position retention during power-off conditions must be provided by the drive or external mechanics.
Frequently Asked Questions about MHP112B-024-HG0-ANNNNN:
Q: Is a holding brake included in the MHP112B-024-HG0-ANNNNN motor?
A: This model operates without a holding brake installed.
Q: What type of drive shaft does the MHP112B-024-HG0-ANNNNN feature?
A: The motor is equipped with a plain shaft that includes a sealing ring for protection against contaminants.
Q: What feedback system is used on the MHP112B-024-HG0-ANNNNN synchronous motor?
A: The MHP112B-024-HG0-ANNNNN uses an incremental encoder with 2048 increments for feedback.
Q: What level of environmental protection does the MHP112B-024-HG0-ANNNNN provide?
A: The protection category is IP65, ensuring the motor is dust-tight and protected against water jets.
Q: What is the standstill continuous torque specification for the MHP112B-024-HG0-ANNNNN?
A: Continuous torque at standstill with natural convection ranges from 28.0 to 31.0 Nm for this model.
