MHP093B-058-HG1-BNNNNN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911317629
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
3 Minutes
22 Seconds
The Bosch Rexroth Indramat MHP093B-058-HG1-BNNNNN is part of the MHP Synchronous Motors series and features a continuous standstill torque of 17.5 to 20.0 Nm with housing designed for natural convection. It is equipped with a plain shaft with sealing ring, has a holding brake torque of 20.0 Nm, and offers incremental encoder motor feedback with 2048 increments. This motor is rated for insulation class F and has IP65 protection.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MHP093B-058-HG1-BNNNNN is a synchronous motor produced by Bosch Rexroth Indramat for the MHP Synchronous Motors series. In automated machinery, this unit delivers closed-loop rotary motion by pairing with a compatible drive controller and feedback system, allowing position and speed to be regulated in real time for indexing tables, packaging actuators, and similar axes. It is suited for servo applications that require repeatable starts, stops, and stable holding behavior during normal machine cycles. Its operating profile also fits motion systems where smooth speed regulation and accurate axis response are required.
The motor develops a continuous standstill torque of 17.5 to 20.0 Nm when cooled only by natural convection, and it maintains reliable service within an ambient range of 0 to +40 °C. Protection is rated at IP65, so internal components remain sealed against dust and water jets during wash-down or outdoor installation. Position feedback is provided by an incremental encoder with 2048 increments, supporting precise digital control. When line power is removed, mechanical holding force is supplied by the brake, delivering 20.0 Nm of static torque to keep the load stationary. These capabilities are packaged in a frame identified as size 093 with a type-B length and a natural-convection housing, giving a balance between thermal capacity and compact footprint.
The shaft is a plain shaft with a sealing ring, preventing lubricant migration while coupling directly to pulleys or gearboxes. Power is routed through a connector on side B, simplifying cable management in tight cabinets and helping keep adjacent routing areas clear. The motor uses insulation class F, allowing winding temperatures up to 155 °C without loss of dielectric strength. Electrical characteristics are set by winding code 058, which is used for the resistance and inductance values associated with standard MHP drive parameters. These features support integration into compact machine assemblies where protected shaft sealing and orderly cable exit are important.
Frequently Asked Questions about MHP093B-058-HG1-BNNNNN:
Q: What is the permitted ambient temperature for operating the MHP093B-058-HG1-BNNNNN motor?
A: The allowed ambient temperature range for the MHP093B-058-HG1-BNNNNN is 0 to +40°C.
Q: What is the continuous standstill torque of the MHP093B-058-HG1-BNNNNN motor with natural convection cooling?
A: This model provides continuous torque at standstill between 17.5 and 20.0 Nm when cooled by natural convection.
Q: What type of drive shaft does the MHP093B-058-HG1-BNNNNN have?
A: The drive shaft on this motor is a plain shaft equipped with a sealing ring.
Q: Does the MHP093B-058-HG1-BNNNNN motor have a holding brake, and what is its brake torque?
A: This unit comes with a holding brake, which offers a brake torque of 20.0 Nm.
Q: What protection rating does the MHP093B-058-HG1-BNNNNN offer?
A: The protection category for this model is IP65, providing a high level of protection against dust and water.
