Product Description:

The MHP093B-058-HG0-BNNNNN is a synchronous servo motor manufactured by Bosch Rexroth Indramat for the MHP Synchronous Motors series. This motor serves as a rotary actuator in industrial automation, where precise torque and position control are required for coordinated motion in packaging lines, pick-and-place stations, and material-handling axes. Its synchronous design allows the connected drive to regulate speed and shaft position accurately during repeated start, stop, and indexing movements.

With natural convection cooling, the motor can supply a continuous standstill torque of 17.5 to 20.0 Nm, allowing it to hold or slowly move loads without external airflow. The housing is sealed to IP65, which helps keep dust and low-pressure water jets away from internal components. Operation is permitted in ambient temperatures from 0 to +40 °C, matching typical industrial conditions. Thermal endurance is supported by class F insulation, which withstands winding temperatures up to 155 °C before insulation life is reduced. For position feedback, an incremental encoder with 2048 increments reports shaft movement to the drive controller, enabling fine resolution during speed regulation and homing routines.

The motor uses a plain shaft with a sealing ring for power transmission while helping limit contaminant entry around the shaft interface. It is supplied without a holding brake, so vertical or over-running loads require an external holding method when power is removed. Power leads exit through a rear-facing right-angle connection identified as a connector on side B, which can simplify cable routing in tight machine spaces. The 058 winding code corresponds to the electrical characteristics matched to compatible Rexroth drives. Its B-length, 093-frame geometry supports installation where a compact servo package with sealed housing and direct feedback is required.
