The Bosch Rexroth Indramat MHD115B-024-PG1-AN is a servo motor from the MHD Synchronous Motors series. It features a continuous torque at standstill of 50.0 Nm and is equipped with a holding brake providing 70.0 Nm of torque. The motor is liquid cooled, has a flange size of 192 mm, and uses digital servo feedback with an integrated encoder for absolute position detection.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MHD115B-024-PG1-AN is a servo motor manufactured by Bosch Rexroth Indramat within the MHD Synchronous Motors series. Designed for industrial automation, it delivers controlled rotary motion for feed drives, pick-and-place heads, and other CNC axes where closed-loop precision is required. Its permanent-magnet rotor and integrated position electronics place motion generation and feedback in one housing, which helps keep the machine layout compact. When paired with compatible Indramat digital controllers, the motor supports programmable acceleration profiles and continuous position monitoring during dynamic axis movement.
Mechanical output is governed by a continuous standstill torque of 50.0 Nm, allowing the axis to resist load at zero speed without overheating under rated conditions. When power is removed, the integral holding brake applies 70.0 Nm of static torque to secure the shaft in place. A centering diameter of 180 mm aligns the motor with precision housings, while the 192 mm square flange provides a standardized mounting surface for rigid installation. Heat from the stator is removed by liquid cooling channels in the housing, and power and feedback cabling exit toward side A to support straightforward routing inside the machine.
The integrated digital servo feedback encoder supplies absolute feedback for more than 4096 revolutions to the drive controller, so axis position remains available across repeated turns without requiring a separate external transducer. Its plain shaft, machined without a keyway, is fitted with a shaft seal to help limit lubricant or coolant ingress at the output end. Electrical behavior follows winding code 024, which matches the motor to compatible drive settings and supports the B-length rotor stack used for this frame size. This arrangement supports accurate indexing and stable velocity control in packaging, transfer, and gantry applications.
Frequently Asked Questions about MHD115B-024-PG1-AN:
Q: Does the MHD115B-024-PG1-AN motor have a holding brake, and what is its torque?
A: This model is equipped with a holding brake that provides a brake torque of 70.0 Nm.
Q: What is the continuous standstill torque of the MHD115B-024-PG1-AN motor?
A: The MHD115B-024-PG1-AN achieves a continuous torque of 50.0 Nm at standstill.
Q: What type of encoder system does the MHD115B-024-PG1-AN servo motor use?
A: This servo motor utilizes digital servo feedback with an integrated encoder for precise position detection.
Q: What cooling method is used in the housing of the MHD115B-024-PG1-AN motor?
A: The motor features a liquid cooling system for its housing, supporting efficient thermal management.
Q: What type of shaft and seal does the MHD115B-024-PG1-AN motor provide?
A: It is built with a plain shaft design and includes a shaft seal for added protection.
