MHD115A-024-PP1-LA Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911305745
The Bosch Rexroth Indramat MHD115A-024-PP1-LA is a servo motor from the MHD Synchronous Motors series with a continuous torque at standstill of 32.0 Nm and a holding brake torque of 70.0 Nm. It features a keyed shaft design, an IP65 degree of protection, and natural convection cooling. The motor has a digital servo feedback encoder with absolute position detection beyond 4096 revolutions and is equipped with an insulation class F.
Internal Product Review
The MHD115A-024-PP1-LA is a Bosch Rexroth Indramat servo motor with natural convection cooling and IP65 protection. Digital servo feedback with an integrated encoder supports precise motion control, and ±0.5 angular minutes system accuracy adds strong positioning confidence. A holding brake rated at 70.0 Nm makes this unit an excellent choice for secure servo applications.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MHD115A-024-PP1-LA is a servo motor produced by Bosch Rexroth Indramat within the MHD Synchronous Motors series. Designed for closed-loop industrial drive systems, the motor converts electrical energy into controlled mechanical rotation for positioning or speed-regulated axes in packaging, material-handling, and machining equipment. The encoder provides absolute position data for more than 4096 revolutions, and the power connector is oriented to the left of the shaft to simplify cabinet routing.
It provides a continuous standstill torque of 32.0 Nm, allowing the axis to hold load without overheating. The stator-to-housing interface mates to a machine frame through a centering diameter of 180 mm and a four-bolt flange that measures 192 mm across, ensuring precise alignment. An enclosure rating of IP65 protects the windings and integrated digital servo feedback encoder against dust ingress and water jets. Heat is removed by natural convection, so no blower or liquid circuit is required, and the unit can operate continuously within an ambient range of 0 to 40 °C. A keyed shaft transmits torque directly to a coupling, while a shaft seal helps prevent lubricant escape.
For power-off safety, a permanent-magnet holding brake supplies 70.0 Nm of static torque to lock the shaft. Thermal limiting is supported by Class F insulation, permitting winding temperatures up to 155 °C. Motion precision is guided by a system accuracy of ± 0.5 angular minutes, which matches the optically measured absolute feedback and suits multi-axis interpolation tasks. The motor uses winding code 024 and the A length variant of frame size 115, which helps keep mass and inertia low for dynamic cycles. Operation is permitted up to 1000 m above mean sea level before derating, and storage is permitted between -20 and +80 °C.
