Product Description:

The MHD115A-024-PG0-AA is a servo motor manufactured by Bosch Rexroth Indramat within the MHD Synchronous Motors series. Designed for positioning and speed-controlled duties in industrial automation, the unit converts drive power from a compatible controller into rotary motion that can be precisely measured by its integrated digital servo feedback encoder. It incorporates absolute position detection over more than 4096 revolutions, allowing closed-loop motion sequences without homing after power-up.

The housing carries a protection rating of IP65, so dust ingress is prevented and the motor tolerates low-pressure water jets during washdown maintenance. At standstill, it delivers 32.0 Nm of continuous torque, a level suited to mid-range gantries, presses, or transfer axes that require sustained holding force. Mounting accuracy is assisted by a 180 mm centering diameter that aligns the 192 mm flange to machine frames. Heat generated in the stator is removed by natural convection, so no external blower or liquid circuit is necessary. The windings can operate where ambient air remains within 0 to 40 °C, and the motor is supplied without a holding brake, so external mechanical stops or drive torque must secure the load when power is removed. Power and feedback connectors exit on side A for orderly cable routing toward the cabinet, and a plain shaft with a shaft seal is provided for direct coupling.

Additional parameters support reliable installation and storage. Overall system accuracy is ± 0.5 angular minutes, which suits applications that need tight positional repeatability. When stored, the unit withstands temperatures from -20 to +80 °C without degradation, and it may be mounted up to 1000 m above mean sea level. A flange size of 192 mm provides a broad mounting surface to distribute radial loads, while insulation class F permits winding temperatures up to 155 °C before thermal limits are reached.
