MHD112D-027-PP0-BN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911280611
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
4 Minutes
20 Seconds
The Bosch Rexroth Indramat MHD112D-027-PP0-BN is a servo motor from the MHD Synchronous Motors series featuring a continuous standstill torque of 48.0 Nm and a keyed shaft with shaft seal. It is equipped with digital servo feedback and an integrated encoder that supports absolute position detection beyond 4096 revolutions. This model uses liquid cooling and has a flange size of 192 mm without a holding brake.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MHD112D-027-PP0-BN is a servo motor produced by Bosch Rexroth Indramat for the MHD Synchronous Motors series. This model serves as a rotary actuator in industrial automation systems, converting drive current into tightly regulated mechanical motion for positioning tables, gantries, and tooling spindles. It can be paired with a compatible drive to support accurate speed control and repeatable positioning on production equipment. Its design suits machine axes that need stable torque response during frequent starts, stops, and direction changes. It is built in motor length D with liquid channels molded into the housing and integrates digital servo feedback for closed-loop operation. The motor is supplied without a holding brake, so any static load retention must be handled by external mechanics or the drive itself.
The motor can supply a continuous standstill torque of 48.0 Nm, allowing the axis to hold demanding loads while remaining within thermal limits. A flange measuring 192 mm sets the mounting bolt pattern, and the housing uses liquid cooling to remove copper losses during prolonged duty cycles. This cooling method carries heat away more effectively than passive cooling, which helps the motor maintain output in enclosed or high-duty installations. Power is transmitted through a keyed shaft, giving positive mechanical engagement with couplings or pulleys. Accurate alignment with the machine frame is established by a centering pilot of 130 mm, which helps the motor seat correctly during installation.
Rotor position is reported to the drive through absolute feedback for more than 4096 revolutions, so the controller knows the true shaft angle immediately after power-up. Multi-turn absolute feedback is useful on axes that must return to operation from a known position after power cycling. The power terminations use an output connector on side B, which helps route cables along the machine frame and can reduce bending at the connector. The winding uses code 027, and the motor has frame size 112 within the series. A shaft seal is fitted to help protect the internal bearings from coolant splashes and fine dust.
Frequently Asked Questions about MHD112D-027-PP0-BN:
Q: What kind of position detection does the MHD112D-027-PP0-BN provide?
A: This model is equipped with an absolute encoder capable of position detection beyond 4096 revolutions.
Q: What is the continuous torque at standstill for this motor?
A: The MHD112D-027-PP0-BN delivers a continuous standstill torque of 48.0 Nm.
Q: Does the MHD112D-027-PP0-BN include a holding brake?
A: This motor does not include a holding brake.
Q: How is the MHD112D-027-PP0-BN motor cooled?
A: Cooling for the MHD112D-027-PP0-BN is achieved through liquid cooling.
Q: What is the direction and type of power connection for this motor?
A: The power connection on this model exits towards side B via an output connector.
