MHD112D-027-NG0-AN

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
MHD Series Synchronous motors manufactured by Indramat, Bosch, Rexroth. This Motor features a Motor Encoder of Digital servo feedback along with a Motor Frame Size number of 192mm Flange Size, 130mm Centering Diameter.

MHD112D-027-NG0-AN

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
MHD Series Synchronous motors manufactured by Indramat, Bosch, Rexroth. This Motor features a Motor Encoder of Digital servo feedback along with a Motor Frame Size number of 192mm Flange Size, 130mm Centering Diameter.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a MHD112D-027-NG0-AN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Mechanical products are quite expensive to acquire and you want to get a product whose price matches the value. Since that is Bosch Rexroth’s commitment, the company has been able to earn such an enviable position by the use of recent technology to make highly-integrated systems. Their high-end mechanical products are made with the customer’s satisfaction and safety in mind. As such, products like the synchronous motors are exceptionally durable, robust, and multifunctional and occur in various sizes to suit various appliances and machinery. One such product is the MHD112D-027-NG0-AN synchronous motor. Below, we elaborate on various specific technical information for the optimal performance of your motor.

Firstly, synchronous motors utilize liquid, natural or surface cooling categories. In surface and liquid cooling technique, you can expect the over temperature of the MHD112D-027-NG0-AN to be 60K/100 while in cooling the motor naturally, the overtemperature is 60 K – 100K.

The electric parameters are equally important. When the motor is stationary, the continuous current is 47.4 A for surface cooling and a range of 31.6-40.2A when cooling occurs naturally. In liquid cooling, continuous torque and continuous current are unavailable.

When the MHD112D-027-NG0-AN is at standstill, its continuous torque in natural cooling technique is 48Nm to 57Nm and 72.0Nm in surface cooling methods. No matter the cooling method you choose, the MHD112D-027-NG0-AN synchronous motor speed will remain at 3000 min-1 and the peak current 142.2A. If you maintain your motor at 20°C, the expected constant voltage (eff) is 154.5 V/1000min-1 with four pole pairs. At the same temperature, the winding inductivity is 5.65Mh, a torque constant of 1.7 Nm/A and winding resistance of 0.35 Ohms. Finally, the MHD112D-027-NG0-AN has a rated speed of 2000 min-1 whether you use natural, liquid or surface cooling.



  • MHD 112D 027 NG0 AN
  • MHD 112D-027-NG0-AN
  • MHD-112D-027-NG0-AN
  • MHD112D-O27-NGO-AN
  • MHD112D027NG0AN
  • MHDII2D-027-NG0-AN

MHD112D-027-NG0-AN Technical Specifications

Product Group: MHD
Motor Frame Size: 192mm Flange Size, 130mm Centering Diameter
Motor Frame Length: 48.0 Nm
Winding Code: 027
Motor Encoder: Digital servo feedback
Output Shaft: Plain shaft (with shaft sealing ring)
Holding Brake: Without holding brake
Output Direction of Power Connector: Output connector in direction of side A
Housing Type: For liquid cooling
