MHD112D-024-PG0-BN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911281824
The Bosch Rexroth Indramat MHD112D-024-PG0-BN is a servo motor from the MHD Synchronous Motors series featuring a continuous torque at standstill of 48.0 Nm and a degree of protection rated at IP65. The unit has a flange size of 192 mm, uses liquid cooling, and operates with a plain shaft design and a digital servo feedback encoder. It is built with insulation class F and supports system accuracy of ±0.5 angular minutes.
Internal Product Review
The MHD112D-024-PG0-BN is a Bosch Rexroth Indramat servo motor with liquid cooling and IP65 protection. Digital servo feedback with an integrated encoder and absolute position detection beyond 4096 revolutions support precise closed-loop motion. A 48.0 Nm continuous torque at standstill and shaft seal make the unit an excellent choice for demanding servo applications.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MHD112D-024-PG0-BN is a servo motor produced by Bosch Rexroth Indramat as part of the MHD Synchronous Motors series. Built for industrial automation, it converts drive current into controlled mechanical rotation for packaging lines, metalworking centers, and material-handling axes. The model follows winding code 024 and the 112 size classification, and it uses an absolute position transducer that tracks more than 4096 motor revolutions. Digital servo feedback from the integrated encoder lets the controller issue real-time corrections, supporting synchronized motion where repeatable accuracy is required. Because the feedback system is absolute and multi-turn, axis position can remain available after power interruptions without losing the accumulated rotation count.
At the mechanical interface, the motor uses a 192 mm square flange to align directly to gearboxes, while a plain shaft with a shaft seal helps retain lubricant. A continuous standstill torque of 48.0 Nm lets the rotor support static loads, and the housing uses liquid cooling to remove heat produced at rated current. The enclosure is sealed to IP65, protecting internal components from dust and low-pressure water jets. Optical measurement keeps system deviation within ± 0.5 angular minutes, which supports accurate positioning in closed-loop operation. Power exits on side B through an output connector, and length code D adds active material to increase torque without making the motor excessively long.
The allowed ambient range is 0 to 40 °C, and storage can span -20 to +80 °C without demagnetizing the rotor. Class F insulation tolerates winding temperatures up to 155 °C when the installation site is no higher than 1000 m above sea level. The motor also has a 130 mm centering diameter for accurate mounting to the machine face. It is supplied without a holding brake, so any axis that must remain fixed at standstill needs holding torque from the drive or an external braking device. These operating limits suit enclosed industrial equipment where thermal conditions are kept within the stated range.
