MHD112B-048-PG1-RN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911294679
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
5 Minutes
14 Seconds
The Bosch Rexroth Indramat MHD112B-048-PG1-RN is a servo motor from the MHD Synchronous Motors series, featuring a flange size of 192 mm and a centering diameter of 130 mm. It offers liquid cooling, a holding brake with 22 Nm torque, and has a continuous standstill torque of 28 Nm. The motor is equipped with digital servo feedback and integrated encoder with absolute position detection.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MHD112B-048-PG1-RN is a synchronous servo motor produced by Bosch Rexroth Indramat for the MHD Synchronous Motors series. It converts drive current into controlled rotary motion for positioning tasks in packaging lines, transfer systems, and other automated machinery. A digital servo feedback encoder is integrated for absolute position detection beyond 4096 revolutions, and the unit uses an optical measurement method to report rotor angle directly to the drive. This arrangement gives the controller position information across multiple turns instead of only within one revolution. It also supports stable feedback during synchronized moves, indexing sequences, and precise speed control.
The motor mounts to machines with a centering diameter of 130 mm and a flange that spans 192 mm, giving a stable interface for the size-112 frame. These dimensions help the motor seat accurately against the machine face and keep shaft alignment consistent. At standstill, it can deliver 28.0 Nm of continuous torque, and liquid cooling removes heat through the housing to support sustained output. The housing is rated IP65, which helps keep dust and water jets away from internal components. A plain shaft transmits power, and a shaft seal is fitted to limit contaminant entry and lubricant loss. The B-length stator, right-side power connector, and single cable for phase conductors help keep machine-side cable routing orderly.
A permanent-magnet holding brake supplies 22.0 Nm to keep the load stationary when power is off. The insulation system is graded Class F, allowing winding temperatures up to 155 °C during normal duty. Position repeatability is held within ± 0.5 angular minutes, which supports accurate placement in multi-axis assemblies where small angular errors can affect overall motion quality. The motor operates in ambient air from 0 to 40 °C, and storage is permitted from −20 °C to +80 °C. Installation is permitted up to 1000 m above mean sea level without derating, which suits typical indoor industrial elevations.
Frequently Asked Questions about MHD112B-048-PG1-RN:
Q: What cooling method is used for the MHD112B-048-PG1-RN motor housing?
A: The MHD112B-048-PG1-RN features a liquid cooling system for its housing to manage operating temperatures efficiently.
Q: Does the MHD112B-048-PG1-RN include a holding brake and what torque does it provide?
A: This model is equipped with a holding brake offering 22.0 Nm of torque.
Q: What type of shaft and seal does the MHD112B-048-PG1-RN motor use?
A: The shaft of this motor has a plain design and includes a shaft seal for added protection.
Q: What is the type and range of position detection for the MHD112B-048-PG1-RN?
A: The MHD112B-048-PG1-RN provides absolute position detection for more than 4096 revolutions.
Q: What level of ingress protection does the MHD112B-048-PG1-RN motor offer?
A: This motor is rated with a degree of protection at IP65, guarding it from dust and water jets.
