The Bosch Rexroth Indramat MHD112A-035-PP0-BN is a servo motor from the MHD Synchronous Motors series featuring liquid cooling and IP65 protection. It provides a continuous torque at standstill of 15 Nm and uses a keyed shaft with shaft seal. The motor is equipped with digital servo feedback with integrated encoder and operates within an ambient temperature range of 0 to 40 °C.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MHD112A-035-PP0-BN servo motor is part of the MHD Synchronous Motors series from Bosch Rexroth Indramat. Designed for closed-loop positioning tasks, the motor turns electrical energy from an Indramat drive into precisely controlled rotation for conveyors, packaging stations, and handling axes. Frame size 112 and winding code 035 set its electromagnetic layout and match it to drives that can deliver the required current and voltage. This arrangement supports accurate speed and position control during repeated start-stop cycles.
The motor supplies a continuous standstill torque of 15.0 Nm, enabling stable force delivery when the shaft is held motionless under load. Protection to IP65 prevents dust ingress and water jets, while the stator jacket uses liquid cooling to remove heat so the rated output can be maintained without derating. It operates in ambient temperatures from 0 to 40 °C, and its 130 mm centering diameter aligns the flange precisely on machine frames. Digital servo feedback with an integrated encoder provides high-resolution speed and position data through an optical measurement method with low hysteresis. Class F insulation helps the windings tolerate elevated internal temperatures during operation. The PP0 variant is supplied without a holding brake, which reduces mass in applications that rely on drive-side dynamic braking.
The motor uses a keyed shaft for torque transfer, and the front face follows the DIN flange pattern with a diameter of 192 mm. The encoder provides absolute (>4096 revolutions) position detection and supports repeatability of ±0.5 angular minutes, enabling fine alignment in multi-axis assemblies. The power line exits through an output connector on side B, and a shaft seal is fitted to block contaminants. The side-B connector arrangement can simplify cable routing in installations with limited space near the mounting face. The unit may be stored between −20 and +80 °C and installed at elevations up to 1000 m above sea level. Its length code A keeps the overall depth minimal.
Frequently Asked Questions about MHD112A-035-PP0-BN:
Q: What cooling method is used in the MHD112A-035-PP0-BN motor?
A: This model features a liquid cooling system for more efficient heat dissipation during demanding operations.
Q: What is the continuous torque at standstill for the MHD112A-035-PP0-BN?
A: The servo motor has a continuous torque rating of 15.0 Nm at standstill.
Q: What type of position detection is provided by the MHD112A-035-PP0-BN?
A: This motor achieves absolute position detection and can track more than 4096 revolutions.
Q: What kind of shaft design does the MHD112A-035-PP0-BN have?
A: The MHD112A-035-PP0-BN uses a keyed shaft design for secure mechanical coupling.
Q: What is the degree of protection of the MHD112A-035-PP0-BN servo motor?
A: The degree of protection for this model is rated at IP65, ensuring full protection against dust and water jets.
