The Bosch Rexroth Indramat MHD112A-024-PG1-BN is a servo motor from the MHD Synchronous Motors series with a continuous standstill torque of 15.0 Nm and IP65 degree of protection. It features liquid cooling, a centering diameter of 130 mm, and comes with a holding brake that provides 22.0 Nm of torque. The motor is equipped with digital servo feedback using an integrated encoder for position detection over more than 4096 revolutions.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MHD112A-024-PG1-BN belongs to the MHD Synchronous Motors series produced by Bosch Rexroth Indramat. It is a servo motor intended for closed-loop motion axes in automated machinery, where the integrated digital feedback works with a drive controller to maintain commanded position and velocity. The optical encoder tracks rotor position, and its feedback data helps the axis respond accurately during acceleration, deceleration, and steady-state operation.
This motor delivers a continuous standstill torque of 15.0 Nm, allowing static load holding without overheating. The housing meets the IP65 ingress rating, so dust and low-pressure water jets do not reach internal windings. Heat generated in service is removed through liquid cooling, which keeps the frame temperature stable and supports higher duty cycles than air-cooled units. A square mounting interface with a 192 mm flange aligns the stator to gearboxes or machine plates. A holding brake rated at 22.0 Nm secures vertical loads during power loss. Electrical insulation is built to class F standards, giving the stator varnish a 155 °C thermal limit. A 130 mm centering diameter positions the motor concentrically, the plain shaft transmits torque without a key, and the power connector is oriented on side B for straightforward cable routing. The plain shaft is suited to friction-based couplings that do not require a keyway.
Total system precision is supported by a feedback chain that reaches ± 0.5 angular minutes, and absolute position detection over 4096 revolutions eliminates homing routines after shutdown. Safe storage is permitted from -20 to +80 °C, while normal operation must remain within 0 to 40 °C so the coolant can manage losses effectively. Installation is permitted up to 1000 m above sea level without derating. A shaft seal helps keep coolant or oil away from the bearing journal.
Frequently Asked Questions about MHD112A-024-PG1-BN:
Q: How is the MHD112A-024-PG1-BN motor cooled?
A: The MHD112A-024-PG1-BN motor utilizes liquid cooling to maintain optimal operating temperatures.
Q: What type of shaft does the MHD112A-024-PG1-BN have?
A: This motor features a plain shaft with an integrated shaft seal for added protection against contaminants.
Q: Is the MHD112A-024-PG1-BN motor equipped with a holding brake and what is its torque?
A: The MHD112A-024-PG1-BN includes a holding brake with a torque capacity of 22.0 Nm.
Q: What is the degree of protection for the MHD112A-024-PG1-BN motor?
A: The degree of protection for this model is rated at IP65, enabling it to resist dust and low-pressure water jets.
Q: What type of position feedback is provided on the MHD112A-024-PG1-BN motor?
A: This motor uses digital servo feedback with an integrated optical encoder for precise absolute position detection over more than 4096 revolutions.
