The Bosch Rexroth Indramat MHD093C-058-PP1-AN is a servo motor in the MHD Synchronous Motors series, featuring liquid cooling and a flange size of 140 or 150 mm. It provides a continuous torque at standstill of 23.0 Nm, has a keyed shaft with shaft seal, and includes a holding brake with 22.0 Nm of torque. The motor uses digital servo feedback with an integrated encoder for absolute position detection over more than 4096 revolutions.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MHD093C-058-PP1-AN is a servo motor built by Bosch Rexroth Indramat for the MHD Synchronous Motors series. As a drive element, it delivers closed-loop positioning for gantries, packaging stations, and transfer axes, integrating digital servo feedback to synchronize motion with the automation controller. The frame combines motor size 093 with length code C, giving it a medium motor envelope for machines that need higher torque without a larger installation footprint. That layout supports repeatable motion on axes that must start, stop, and hold position under changing load conditions.
During static hold, the motor provides 23.0 Nm of continuous torque, allowing it to support stationary loads without thermal overload. A housing that uses liquid cooling extracts heat directly from the stator, so rated output can be maintained in compact, sealed cabinets. The centering pilot of 130 mm aligns the flange precisely to a mating gearbox or mounting plate, and the dual bolt circle of 140 / 150 mm accommodates common flange patterns. Power conductors exit on side A through an industrial output connector, which keeps cable routing straightforward. Digital servo feedback with an integrated encoder supplies absolute position data to the drive, and a shaft seal helps block coolant spray or oil mist from entering the housing. This arrangement suits enclosed machine sections where direct airflow is limited.
A spring-applied brake supplies 22.0 Nm of holding torque, so vertical axes remain stationary when power is removed. The output shaft uses a keyed shaft profile for positive engagement with couplings and pulleys. Position detection uses absolute feedback over more than 4096 revolutions, so the axis can retain multi-turn position information after startup. This helps the system resume operation without a reference move in many applications. The motor uses winding code 058, which corresponds to the electrical values expected by compatible drives.
Frequently Asked Questions about MHD093C-058-PP1-AN:
Q: What type of cooling does the MHD093C-058-PP1-AN motor use?
A: This motor uses liquid cooling to efficiently manage operating temperatures.
Q: What is the holding brake torque for the MHD093C-058-PP1-AN?
A: The holding brake on this model produces a torque of 22.0 Nm.
Q: What shaft design is featured on the MHD093C-058-PP1-AN motor?
A: A keyed shaft design is used on this motor for mechanical coupling.
Q: What kind of encoder does the MHD093C-058-PP1-AN use for feedback?
A: This motor includes digital servo feedback with an integrated encoder for position detection.
Q: What is the continuous torque at standstill for the MHD093C-058-PP1-AN?
A: The MHD093C-058-PP1-AN delivers a continuous torque at standstill of 23.0 Nm.
