The Bosch Rexroth Indramat MHD093C-035-PP0-BN is a servo motor from the MHD Synchronous Motors series with a continuous torque at standstill of 23.0 Nm and a keyed shaft design with a shaft seal. It features liquid cooling, a centering diameter of 130 mm, a flange size of 140 or 150 mm, and an absolute digital servo feedback encoder that supports over 4096 revolutions.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MHD093C-035-PP0-BN is a servo motor manufactured by Bosch Rexroth Indramat and assigned to the MHD Synchronous Motors series. It converts electrical energy into regulated mechanical rotation so that automated conveyors, gantries, and processing stations can position loads with repeatable accuracy. Integration of an absolute encoder and drive-side diagnostics makes the unit suitable for closed-loop control tasks where both speed stability and dynamic torque are required. This arrangement supports accurate motion control in machines that must start, stop, and reverse under changing load conditions.
The motor can sustain 23.0 Nm at standstill without overheating, which indicates its continuous torque capability for feed axes or pressing applications that dwell under load. Thermal management is assisted by liquid cooling that circulates through the housing to remove copper and iron losses. This cooling method reduces reliance on surrounding airflow and supports stable thermal behavior during sustained duty. A centering diameter of 130 mm aligns the stator on the mounting pilot, while the front face matches a flange of 140 / 150 mm so it can bolt directly to standardized gearboxes or machine plates. Electrical performance is matched to winding code 035 and motor size 093, which correspond to the winding layout and frame dimensions used by the drive system. The C length extends the active iron stack to raise torque without changing the footprint. Feedback is provided through digital servo electronics integrated behind the flange, and the power conductors exit through an output connector that helps keep cable routing orderly.
A keyed shaft transmits torque without slip and enables repeatable coupling to pulleys or couplings. Position data remain valid over more than 4096 revolutions, giving the controller a wide capture range after power cycling. That feedback retention is useful on transfer axes that must recover position quickly after routine power interruptions. For streamlined cabinet wiring, the three-phase power lead is routed toward side B of the housing. The motor ships without a holding brake, so external locking or active drive torque must secure stationary loads, and a shaft seal is included to limit lubricant migration along the output journal.
Frequently Asked Questions about MHD093C-035-PP0-BN:
Q: What type of cooling does the MHD093C-035-PP0-BN synchronous motor use?
A: The MHD093C-035-PP0-BN motor features liquid cooling for temperature management.
Q: What is the continuous standstill torque of the MHD093C-035-PP0-BN motor?
A: This model provides a continuous torque of 23.0 Nm at standstill.
Q: What type of encoder and position detection does the MHD093C-035-PP0-BN have?
A: The encoder on this motor is a digital servo feedback with an integrated encoder, supporting absolute position detection for over 4096 revolutions.
Q: What shaft configuration does the MHD093C-035-PP0-BN feature?
A: The MHD093C-035-PP0-BN comes with a keyed shaft and a shaft seal installed.
Q: Does the MHD093C-035-PP0-BN motor come with a holding brake?
A: This model does not include a holding brake.
