MHD093C-035-NG0-BA

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
MHD Series Synchronous motors manufactured by Indramat, Bosch, Rexroth. This Motor features a Motor Encoder of Digital servo feedback along with a Motor Frame Size number of 140/150mm Flange Size, 130mm Centering Diameter.

MHD093C-035-NG0-BA

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
MHD Series Synchronous motors manufactured by Indramat, Bosch, Rexroth. This Motor features a Motor Encoder of Digital servo feedback along with a Motor Frame Size number of 140/150mm Flange Size, 130mm Centering Diameter.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a MHD093C-035-NG0-BA to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

This part is another MHD synchronous motor from Bosch Rexroth. The MHD093C-035-NG0-BA is a very cost-effective choice and is also quite reliable. The motor features a centering diameter of 130 mm and has a 140/150 mm flange size. Its motor frame length is 23 Nm and it has a winding code of 35. The motor encoder feedback type is digital servo feedback and the output shaft is a plain shaft with a shaft sealing ring. This motor comes without holding break and the output connector can be found in the direction of the side B. The housing type is designed to provide natural convection and the motor uses a cooling type of liquid.

It is possible to use this motor under adverse environmental conditions because it features temperature monitoring, cooling features and IP 65 protection that helps to prevent overload to the motor. With a housing design that allows for natural convection, heat is transferred outside of the motor’s housing to provide cooling to the unit. The motor also provides high dynamics thanks to its favorable torque to inertia mass ratio. Thanks to electronic commutation, peak torque can be used across a range of speeds. There is also electrical commutation that allows the motor to operate efficiently through multiple start-stop cycles even when there is a high repeat of these instances.

The MHD093C-035-NG0-BA synchronous motor is made with easy attachment in mind. It can be attached easily thanks to the DIN 424948 flange. The unit can support any position you desire for installation. Belt pulleys and mounting pinions allow for direct overhung mounting. Cabling can also be done easily with many cable sets available that work well with this system.

  • MHD 093C 035 NG0 BA
  • MHD 093C-035-NG0-BA
  • MHD-093C-035-NG0-BA
  • MHD093C035NG0BA
  • MHDO93C-O35-NGO-BA

MHD093C-035-NG0-BA Technical Specifications

Product Group: MHD
Motor Frame Size: 140/150mm Flange Size, 130mm Centering Diameter
Motor Frame Length: 23.0 Nm
Winding Code: 035
Motor Encoder: Digital servo feedback
Output Shaft: Plain shaft (with shaft sealing ring)
Holding Brake: Without holding brake
Output Direction of Power Connector: Output connector in direction of side B
Housing Type: For natural convection
