Product Description:

The MHD093B-035-PG1-BA belongs to the MHD Synchronous Motors series produced by Bosch Rexroth Indramat. It is a servo motor intended for closed-loop axis control in industrial automation, where precise velocity and position regulation are required for machine tools, packaging lines, and handling modules. When paired with a compatible drive, it converts commanded current into controlled rotary motion for repeatable positioning and speed control. Its design suits feed axes, indexing tables, and transfer systems that require stable torque at standstill, smooth acceleration, and accurate motion during short, repetitive machine cycles. The motor uses optical feedback measurement, and its B length matches the 093 frame size.

The motor delivers a continuous standstill torque of 17.5 Nm, allowing holding or low-speed duties without thermal overload. Protection level IP65 seals the housing against dust and water jets, making cabinet-free mounting feasible in many plant environments. Position data is generated by digital servo feedback with an optical absolute encoder that supports more than 4096 revolutions. A built-in holding brake supplies 22.0 Nm to secure vertical or suspended loads when power is removed. Heat is removed by natural convection, so additional fans are unnecessary when the ambient temperature remains between 0 and 40 °C. The motor has a plain shaft with a shaft seal, which helps prevent lubricant escape. Power wiring exits on side B through an output connector, and the motor uses winding code 035 with insulation class F.

System accuracy reaches ± 0.5 angular minutes, which supports precise contouring when combined with a high-resolution drive. Storage is permissible between -20 to +80 °C, and the unit can operate at installation sites up to 1000 m above sea level. The flange span of 140 / 150 mm fits machine interfaces in the same mechanical envelope. This mounting span also suits common gearbox faces and adapter plates used in industrial motion systems.
