The Bosch Rexroth Indramat MHD093B-024-NP1-BA is a servo motor from the MHD Synchronous Motors series that features a keyed shaft and natural convection housing cooling. It provides a continuous torque of 17.5 Nm at standstill, uses a digital servo feedback encoder, and includes an IP65 protection rating. The motor is equipped with a holding brake rated at 22 Nm and operates within an ambient temperature range of 0 to 40 degrees Celsius.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MHD093B-024-NP1-BA belongs to the MHD Synchronous Motors series manufactured by Bosch Rexroth Indramat. It is a servo motor that relies on digital servo feedback of the HSF type and relative position detection to provide closed-loop rotary motion for industrial automation axes. An optical measurement method inside the encoder tracks rotor position so that a drive controller can modulate current and maintain commanded speed or angle in packaging machines, gantries, and general material-handling stations.
The motor can generate a continuous holding capability of 17.5 Nm at standstill without exceeding thermal limits. The housing is sealed to IP65, blocking dust ingress and low-pressure water jets during washdown or airborne-particulate exposure. A spring-applied holding brake delivers 22.0 Nm of static torque so vertical or suspended loads remain secure when the drive is disabled. Operation is permitted in ambient air from 0 to 40 °C, so magnetic and insulation properties stay within their intended limits. Closed-loop precision is supported by a system accuracy of ± 0.5 angular minutes, allowing tight synchronization with linear axes or electronic cams. Additional characteristics include winding code 024, a keyed shaft, and an output connector on side B.
A 130 mm centering diameter helps align the motor to adjacent mechanical interfaces, while the rectangular flange pattern of 140 / 150 mm matches common mounting frames. Class F insulation permits winding temperatures up to 155 °C during cyclic duty. Heat is removed through natural convection, so no external blower or liquid circuit is required. The motor can be stored between −20 and +80 °C and installed at elevations up to 1000 m above mean sea level. It is equipped with a shaft seal to limit lubricant migration. Length code B and size 093 identify the housing envelope used for this motor.
Frequently Asked Questions about MHD093B-024-NP1-BA:
Q: What level of protection does the MHD093B-024-NP1-BA motor provide?
A: The MHD093B-024-NP1-BA features a degree of protection rated at IP65, ensuring resistance to dust and low pressure water jets.
Q: What shaft design is used on the MHD093B-024-NP1-BA motor?
A: This model is equipped with a keyed shaft and includes a shaft seal for secure mechanical coupling and added protection.
Q: What is the holding brake torque available on the MHD093B-024-NP1-BA?
A: The holding brake on this servo motor offers a holding torque of 22.0 Nm.
Q: What type of encoder and accuracy does the MHD093B-024-NP1-BA motor use?
A: The encoder for this servo motor uses digital servo feedback (HSF) for position detection with ±0.5 angular minute accuracy.
Q: Which direction does the power connection face on the MHD093B-024-NP1-BA motor?
A: The power connection on this motor is via an output connector, oriented to side B of the housing.
