MHD093A-024-PG1-AA Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911294621
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
5 Minutes
19 Seconds
The Bosch Rexroth Indramat MHD093A-024-PG1-AA is a servo motor from the MHD Synchronous Motors series and features natural convection cooling and IP65 protection. It provides a continuous torque at standstill of 12.0 Nm and includes a holding brake with 22.0 Nm torque. The motor uses digital servo feedback with an integrated encoder for absolute position detection over more than 4096 revolutions.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MHD093A-024-PG1-AA is a servo motor manufactured by Bosch Rexroth Indramat for the MHD Synchronous Motors series. It is intended for closed-loop positioning and speed control in machine tools, packaging equipment, and material-handling axes that require repeatable motion. In operation, the motor receives regulated current from a matching drive controller and converts it into rotary torque at the shaft. This arrangement supports direct coupling to the driven axis while keeping the installation compact. It is suitable for axes that need accurate starts, stops, and repeatable speed changes.
The motor produces a continuous standstill torque of 12.0 Nm, which provides steady holding force while the axis is energized but not rotating. A centering diameter of 130 mm and a flange pattern of 140 / 150 mm provide the mechanical interface for rigid mounting. Once installed, the housing reaches IP65 protection, which helps keep dust and low-pressure water jets away from internal components. Cooling is handled by natural convection, so no external blower is required during operation in ambient temperatures from 0 to 40 °C. The motor uses Insulation Class F windings with winding code 024, and the 093 frame with A length gives a compact form factor. A plain shaft with a shaft seal and the power connector on side A complete the layout.
An integrated holding brake rated at 22.0 Nm secures vertical or suspended loads when power is removed. The digital feedback system uses optical measurement and absolute position detection over more than 4096 revolutions, supporting closed-loop control with system accuracy of ± 0.5 arcminutes. This feedback arrangement allows the drive to monitor shaft position continuously during indexing and speed-regulated motion. For storage, the motor can remain in temperatures from -20 to +80 °C. Installation altitude should not exceed 1000 m above mean sea level.
Frequently Asked Questions about MHD093A-024-PG1-AA:
Q: What is the continuous torque at standstill for the MHD093A-024-PG1-AA motor?
A: The MHD093A-024-PG1-AA has a continuous standstill torque of 12.0 Nm, supporting stable and lasting motor output.
Q: Does the MHD093A-024-PG1-AA motor include a holding brake?
A: This model is equipped with a holding brake that delivers a braking torque of 22.0 Nm.
Q: What type of encoder and position detection is used in the MHD093A-024-PG1-AA?
A: The encoder provides digital servo feedback with integrated absolute position detection for more than 4096 revolutions.
Q: What level of protection against dust and water does the MHD093A-024-PG1-AA offer?
A: The degree of protection of this motor is rated at IP65, which means it is fully dust-tight and protected against low-pressure water jets.
Q: What is the shaft design featured on the MHD093A-024-PG1-AA?
A: The shaft on this model has a plain design and includes a shaft seal to help prevent the ingress of contaminants.
