MHD090B-035-PG1-UN

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
The MHD090B-035-PG1-UN Magent Motor is manufactured by Rexroth Indramat Bosch. This motor has a Winding Code of 35 and has a Multiturn Motor Encoder. The Driven Shaft for this motor is Plain and it is Equipped with a Holding Brake.

MHD090B-035-PG1-UN

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
The MHD090B-035-PG1-UN Magent Motor is manufactured by Rexroth Indramat Bosch. This motor has a Winding Code of 35 and has a Multiturn Motor Encoder. The Driven Shaft for this motor is Plain and it is Equipped with a Holding Brake.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a MHD090B-035-PG1-UN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Bosch Rexroth is an engineering and manufacturing firm that has secured one of the top positions because of utilizing highly integrated systems and components to offer long term and powerful solutions to the automation and intelligence industries. The scalable and dynamic synchronous motors allow users to accommodate diverse appliances. One such motor is the MHD090B-035-PG1-UN which utilizes either liquid, natural or natural cooling system.

For MHD090B-035-PG1-UN when using natural cooling, the rated current is 4.7A to 6.7A, and an estimated value of 9.7A in surface cooling and the rated current is unavailable in liquid cooling. If you are using natural cooling, your rated performance is expected to be 2.8Kw to 4.0Kw and 5.9Kw for surface cooling. The rated voltage is 399V for surface cooling and 354V to 369V for natural cooling and a rated frequency of 200Hz regardless of your cooling method.

Another essential technical information surrounds the mechanical parameters of the MHD090B-035-PG1-UN motor. The theoretical maximum torque is 43.5Nm and the moment of inertia of the rotor is 43.0 x 10-4 kgm². The minimum strand cross-section across the surface and natural cooling systems is 1.0 mm2 which is unavailable in liquid cooling. The time constant for MHD090B-035-PG1-UN motor is 60 min for natural cooling and 30 minutes for surface cooling and lieferbar for liquid cooling. The maximum speed is 5000 min-1 and its mass is 14kgs.

When transporting or storing the motor, the appropriate temperature is -20 to +80°C and the allowable ambient temperature is °C 0 to 40. During setup, the maximum permissible attitude is 1000 meters above the sea level with a degree of protection of 7 IP65. The insulation class of MHD090B-035-PG1-UN is F in accordance with the DIN VDE 0530 Part 1. This product is available from Wake Industrial with a one-year warranty period.

  • MHD090B035PG1UN
  • MHD090B 035 PG1 UN
  • mhd090b-035-pg1-un

MHD090B-035-PG1-UN Technical Specifications

Driven Shaft: Plain
Holding Brake: Equipped
Motor Encoder: Multiturn
Winding Code: 35
