Product Description:

The MAC093A-0-PS-4-C-130-A-0-WI518LV-S001 is produced by Bosch Rexroth Indramat in the MAC AC Servo Motors series. Classified as a motor for analog drive systems, it converts current from legacy amplifiers into accurately regulated shaft rotation for packaging stations, material-handling modules, and indexing tables. Its rotary output is monitored through tachogenerator and encoder signals so motion controllers can keep speed and position errors within tolerance during continuous industrial duty. This arrangement allows the motor to support closed-loop motion tasks where steady response and repeatable shaft movement are required.

The motor has a centering diameter of 130 mm, a frame size code of 093, and a length designation of A. These dimensions help align the shaft with gearboxes or belt pulleys while maintaining repeatable mounting concentricity. Heat is removed solely by natural convection, eliminating the need for blower wiring in compact cabinets. Under rated excitation, the rotor reaches 3000 rpm, giving adequate surface speed for medium-inertia loads without overspeeding standard tooling. The housing layout supports installations where available space, airflow, and shaft alignment all need to remain predictable during operation.

No blocking brake is fitted, so vertical axes must rely on external holding methods. Winding code PS corresponds to the resistance and inductance values used by analog regulators to set current limits. Power enters through a connector on side A, keeping cable bends consistent with other drives mounted in the same row. Position and speed feedback are delivered by a tacho rated at 3 V/1000 rpm and an incremental encoder mounted in the standard housing. These feedback devices provide the drive with the signals needed for speed regulation and position tracking during normal machine operation. The motor uses integrated feedback hardware, so separate external transducers are not required for basic closed-loop control.
