MAC090C-0-KD-4-C/110-B-0/WI529LX/S001
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911232009
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
MAC Permanent Magnet Motor manufactured by Bosch Rexroth Indramat. This motor has a power connecter on Side B. This motor also includes a Incremental Encoder with Standard Mounting encoder and a Not Equipped blocking brake.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MAC090C-0-KD-4-C/110-B-0/WI529LX/S001 motor has a nominal speed of 2000 min-1 and an unchanged torque at standstill of 10.4 Nm (16.0 Nm). It possesses a continuous current at stationary of 17.0 A (26.1 A) and a rotor moment of inertia of 53 x 10-4 kgm2. This motor has a torque steady of 0.68 Nm/A at 20 C, winding resistance of 0.60 Ohm, & winding inductance of 3.6 mH. The highest maximum pulse current is 125 amps, and the thermal time constant is 60 (45) mins. The motor weighs 23 kg & is a reliable choice for an array of industrial applications.
The MAC090A AC motor features a fluid mounting arrangement that allows for arrangements in both B5 & B14. Design B14 provides for winding-equipped flange ties, while design B5 allows for through-hole mounting. Special care needs to be used while installing in configurations IM V3 & IM V19 to avoid liquid collection at the output shaft over time. Despite shaft sealing, liquids can get into the motor housing via the output shaft, requiring regular maintenance to guarantee durability over time.
To maintain the motor's lifetime & efficiency, consider the load on the motor shaft. The Shaft Load Capacity sections provide visualizations of the allowed radial shaft load based on criteria such as average force and speed application location. Furthermore, the presented formulae may be employed to compute the permissible axial shaft load. Following these rules guarantees that the MAC090A AC motor operates reliably in demanding industrial applications while falling within acceptable limits.
